Automatic center clamping tire changer JTC862

Automatic Center Clamping Tire Changer JTC862

Country of origin: China, warranty period - 24 months

The JTC862 is an automatic tire changer with center rim clamping, designed for mounting and dismounting tires on passenger cars, SUVs, and light commercial vehicles. This model features a leverless mounting head to protect rims, a powerful bead breaker cylinder, and an ergonomic design that reduces operator fatigue. Additional features such as the side wheel lift and assist arm make it easier and safer to work with tires of various sizes.

Functions:

• Leverless tool head eliminates the need for traditional tire levers, reducing the risk of damage to tires and rims, while saving time and effort
• Front backlit plastic cover – aesthetic and modern
• Center clamping protects rims from damage
• Side wheel lift reduces back strain
• Powerful aluminum alloy bead breaker cylinder (2800 kg force)
• Assist arm for faster operation with various tire types

Technical specifications:

• Clamping size: 11" – 26"
• Max. wheel diameter: 1100 mm
• Rim width: 3" – 14"
• Bead breaker force: 2800 kg
• Operating pressure: 8 – 10 bar
• Power supply: 200–240 V / 50–60 Hz / 1 phase
• Motor power: 0.85 kW

Standard accessories:

• Tyre paste container
• Paste brush
• Tool head protection
• Bead breaker protection
• Center clamping quick nut
