AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift
AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift

AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift

  • SKU: BD13370
6,558.20 €

AC-HYDRAULIC AC-HYDRAULIC
Prices shown include tax
Add to Cart

Send Message

Description

AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Telescopic pneumatic-hydraulic single cylinder pit lift truck

Description:

- The downgraded design doubles the performance compared to standard pit lifts
- Low construction height with long stroke
- Fast and accurate pneumatic-hydraulic axle hoist with high-speed cylinder
- Simple modern design with control panel and ergonomic working height
- Can be adapted for use with all trucks due to its adjustable body
- The height of the casing is adjusted and adjusted according to the customer's requirements
- Sliding cylinder locking at 800 kg
- Emergency release and overload valve for optimum safety
- Manufacturer: Denmark
- Warranty: 3 years

Technical parameters:

- Lifting capacity: 15 tonnes
- Stroke of piston: 1280 mm
- Minimum height: 900 mm
- Maximum height: 2180 mm
- Lift length: 725 - 1410 mm
- Lift width: 735 mm
- Required compressed air pressure: 8 - 12 bar
- Required compressed air flow: 350 L / min
- Weight: 250 kg
Tags: AC Hydraulic GDT150 telescopic pneumatic hydraulic pit lift , BD13370 , Pit jacks
