Wireless electric vehicle battery charging and discharging device Launch EVP711

Wireless Electric Vehicle Battery Charging and Discharging Device Launch EVP711

Manufacturer: Launch, warranty period – 24 months

The Wireless Electric Vehicle Battery Charging and Discharging Device Launch EVP711 is designed for professional maintenance of lithium-ion and nickel-metal hydride battery modules in electric and hybrid vehicles. The device enables safe charging, discharging, testing, and condition evaluation of battery modules, ensuring accurate SOC and SOH analysis. A wide voltage range, powerful charging and discharging modes, and advanced protection functions allow efficient work with high-voltage battery modules during both diagnostic and repair operations. The EVP711 is developed for service centers that require a safe, reliable, and technologically advanced solution for electric vehicle battery maintenance.

Technical specifications:

• Power supply voltage: AC 220 V
• Frequency: 40–60 Hz
• Charging and discharging voltage range: DC 2–400 V
• Voltage measurement accuracy: ±0.1% FS + 5 mV
• Charging current: up to 100 A, max. 4.4 kW
• Discharging current: up to 150 A, max. 7.2 kW
• Test current: ±1% FS + 0.2 A
• Charging mode: constant current and constant voltage
• Discharging mode: constant current
• Operating temperature: –5 °C to +40 °C
• Data communication: CAN, RS485
• Data storage: USB
• Battery connectors: 16 PIN, 24 PIN
• Channels: HV positive and HV negative
• Display: 10-inch LCD
• Communication: WLAN, Bluetooth

The Wireless Electric Vehicle Battery Charging and Discharging Device Launch EVP711 is a professional choice for service centers working with high-voltage batteries. High power output, advanced protection functions, and real-time data monitoring ensure maximum safety, work efficiency, and extended battery service life. Invest in a reliable Launch solution and take electric vehicle battery maintenance quality to the next level.
