TIG welding machine WIN TIG DC 180 M CEBORA
TIG welding machine WIN TIG DC 180 M CEBORA
New

TIG welding machine WIN TIG DC 180 M CEBORA

  • SKU: BD70757
1,649.00 €

Prices shown include tax

Send Message

Description

TIG welding machine WIN TIG DC 180 M CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below!

WIN TIG DC 180 M is a single-phase inverter TIG and MMA welding machine, designed for maintenance and repair work as well as small production batches. This compact and lightweight unit ensures reliable performance in various industrial sectors including chemical, food, agricultural, automotive bodywork, energy, and metal fabrication. In TIG mode, the arc is ignited either by high frequency or by contact using the “Cebora lift” function.

Functions:
  • TIG and MMA welding in one device
  • Welding current adjustable from 5 to 180 A
  • High-frequency (HF) or contact ignition in TIG mode
  • Possibility to adjust post-gas flow time
  • Adjustable slope-down function for gradual current decrease at the end of welding
  • Lightweight and compact – easy to transport
  • Suitable for a wide range of applications – from chemical to agricultural industries
Technical specifications:
  • Power supply: 230 V ±15% / -20%, 50/60 Hz, single-phase
  • Fuse: 16 A, slow-blow
  • Power in TIG mode: 4 kVA 35%, 2.7 kVA 60%, 2.2 kVA 100%
  • Power in MMA mode: 4.6 kVA 30%, 3.5 kVA 60%, 2.8 kVA 100%
  • Current adjustment range: TIG – 5–180 A, MMA – 10–140 A
  • Duty cycle (10 min at 40 °C):
  • TIG – 180 A 35%, 135 A 60%, 110 A 100%
  • MMA – 140 A 30%, 115 A 60%, 95 A 100%
  • Protection class: IP23
  • Weight: 10.3 kg
  • Dimensions (LxWxH): 171 x 420 x 340 mm
Available accessories:
TIG torch – BINZEL 'ABITIG 200'
  • Standard TIG welding torch designed for comfortable and precise work with various metals.
TIG torch with control function – BINZEL 'ABITIG 200' UP/DOWN
  • This TIG torch features an integrated “UP/DOWN” current control button, allowing the operator to adjust the welding current directly from the torch – especially convenient when working in hard-to-reach areas or when parameter adjustments are needed during welding without using additional control panels.
