Spindle moulder Holzmann FS200

Spindle Moulder Holzmann FS200

Country of origin: Austria, warranty period - 24 months

Note: may be 400V or 230V

The Holzmann FS200 is a compact and reliable spindle moulder designed for professional and precise woodworking tasks. Its sturdy cast iron table, four spindle speed settings, electronic speed indicator, and convenient spindle adjustment system ensure accuracy and ease of operation. Ideal for both smaller workshops and advanced craftsmen.

Features:

• Sturdy cast iron table resistant to torsion and deformation
• High-quality shaper hood with aluminum fences and fine adjustment
• Four different spindle speed settings
• Maximum tool diameter – 200 mm
• Electronic speed display with LED indicators
• Convenient handwheels for spindle adjustment
• Optional sliding table can be installed
• Included: sanding roller, spindle moulder hood with aluminum fences

Technical specifications:

• Motor power S6: 3750 W
• Motor power S1: 2800 W
• Voltage: 400 V
• Table dimensions: 690 x 480 mm
• Table height: 900 mm
• Dust extraction port: Ø 100 mm
• Spindle diameter: 30 mm
• Spindle speeds: 1800 / 3000 / 6000 / 9000 rpm
• Spindle stroke: 100 mm
• Max. clamping height: 105 mm
• Max. tool diameter below table: 190 mm
• Table opening: 200 mm
• Mitre fence dimensions: 360 x 120 mm
• Max. tool diameter above table: 190 mm
• Net weight: 150 kg
• Gross weight: 155 kg
• Packaging height: 680 mm
• Packaging width: 520 mm
• Packaging length: 730 mm
