Semi-automatic tire changer BD-810 + BD310

Semi-automatic tire changer BD-810 + BD310

Country of origin: China, warranty period – 24 months

This semi-automatic tire changer BD-810, together with the auxiliary mounting claw BD310, is a great solution for car repair shops and tire fitting workshops. This combination allows you to quickly and accurately perform tire mounting and demounting work, ensuring a smooth process and minimal effort for the operator. The tire changer BD-810 with BD310 is equipment that makes your work easier, saves time and ensures professional results every time!

Features:

• Steel tire mounting head - this head ensures durability and has replaceable plastic guards that protect the rims from scratches.
• Rim clamping clamps - self-centering rim clamps, they use two pneumatic cylinders to ensure safe and reliable rim clamping.
• Removable pedal mechanism - easier and faster service.
• Retractable mounting arm – the arm rotates horizontally and has a 36 mm hexagonal axle with an axle locking handle.
• Powerful tire release knife – develops a pressing force of up to 2700 kg
• Tire inflation gun with monometer – for convenient and fast tire inflation and pressure check.
• Auxiliary mounting arm BD310 – this arm has a dual operating principle, it can press down one edge of the tire during installation or lift it during installation.

Technical parameters:

• Fixed inner rim diameter: 12” – 24”
• Fixed outer rim diameter: 10” – 22”
• Maximum wheel diameter: 960 mm
• Maximum wheel width: 3” – 15” | 76 – 380 mm
• Tire release force: 2700 kg (27000 N)
• Working pressure of the machine: 8 – 10 bar
• Electric motor power: 1.1 kW
• Machine supply voltage: 230 V / 50 Hz / 1fz

Standard equipment:

• Bucket for tire mounting paste x 1 pc.
• Brush for tire mounting paste x 1 pc.
• Plastic protection for mounting finger x 1 pc.
• Plastic protection for tire release knife x 1 pc.
• Plastic protection for grippers x 4 pcs.
• Mounting / lever x 1 pc.
