Screw air compressor 5.5 kW Comprag

Screw Air Compressor 5.5 kW Comprag

The Comprag 5.5 kW screw compressor is available in the following options:

• 8 bar, 750 l/min
• 10 bar, 650 l/min
• 13 bar, 550 l/min

Functions:

• The F-Series oil-injected screw compressors produce industrial compressed air, optionally equipped with a refrigeration-type air dryer, up to class 4-4-4 according to ISO 8573-1:2010.
• A modern and energy-efficient screw air-end ensures stable air delivery and long-lasting operation.
• The professional t-Log controller automatically manages compressor operation, displaying pressure, temperature, and operating hours.
• An efficient oil separation system ensures a residual oil content of no more than 3 mg/m³.
• A reliable electric motor with a high efficiency rating and thermal overload protection.
• Compact design and easy maintenance – all filters and separators are easily accessible.
• Quiet operation – noise level only 62 dB(A).

Features of the F-Series screw compressors:

• Professional controller.
• Efficient and reliable electric motor.
• Screw-type air-end.
• Effective separation system.

Technical specifications:

• Motor power: 5.5 kW
• Rated voltage: 3/380–420 V/50 Hz
• Noise level: 62 dB(A)
• Connection: 1/2"
• Length: 973 mm
• Width: 724 mm
• Height: 964 mm
• Weight: 285 kg
