Power Testing Stand for Tractors PT 301 MES Series, 600 kW

Power Testing Stand for Tractors PT 301 MES Series, 600 kW

Country of Origin: Germany, warranty period - 24 months

The PT 301 MES power testing stand is a road version, mounted on a trailer capable of being towed at speeds of up to 80 km/h. This model is highly mobile and suitable for use both in workshops and in the field. It is designed for precise measurement of power and torque of tractors and other agricultural machinery, ensuring efficient operation and reliable results.

Other available versions of this model:

• PT 301 MEW: Workshop version, fixed to the floor.
• PT 301 MEM: Workshop version, mobile.
• PT 301 MES: Road version, on a trailer, up to 80 km/h.
• PT 301 K: Street version, on a trailer.

Functions:

• Fast and precise measurement of power and torque
• Mobility – mounted on a trailer, suitable for transport up to 80 km/h
• Digital display showing RPM, torque, and power (kW, HP)
• Ability to measure in both rotational directions
• Efficient air cooling through a high-performance ventilator
• Bluetooth or cable remote control (optional)

Technical Specifications:

• Brake System: 2 retarders (eddy current brakes, maintenance-free)
• Cooling: Air cooling via ventilator (17,000 m³/h)

Measurement Range at 1000 RPM and 20°C:

(Measurement time depends on tractor size and local conditions)

600 kW – 1 min

550 kW – 2 min

500 kW – 2.5 min

450 kW – 3.5 min

400 kW – 4.5 min

320 kW – 7.5 min

280 kW – 9 min

220 kW – 40 min

• Maximum Power: 600 kW (1 min)
• Maximum Torque: 7200 Nm
• Accuracy: <1%
• Maximum Permissible RPM: 3600 1/min
• Power Supply: 400 V/230 V, 16A three-phase
• Dimensions: Length 3100 mm; Width 1800 mm; Height 1580 mm
• Weight: 1300 kg
• Permissible Total Weight: 1800 kg
• Frame/Housing: Galvanized, made from glass fiber-reinforced plastic

Dimensions and Weights:

• PT 301 MEW: Length 1810 mm; Width 730 mm; Height 1540 mm; Weight 1098 kg
• PT 301 MEM: Length 1830 mm; Width 1060 mm; Height 1500 mm; Weight 1150 kg
• PT 301 MES: Length 3100 mm; Width 1800 mm; Height 1580 mm; Weight 1300 kg; Permissible total weight 1800 kg
• PT 301 K: Weight 1600 kg; Permissible total weight 2000 kg

Standard Equipment: CEE plug 5x16A, User manual, Large protective cover (for 301 MES)

Additional Accessories (at extra cost):

• PTZUB-002: “Power Control” software – Cable operation – 1799 EUR
• PTZUB-003: “Power Control” software – Bluetooth operation – 2499 EUR
• PTZUB-019: Device for lifting with a forklift – 1299 EUR
• PTZUB-014: Additional cooling for ventilators – 499 EUR
• PTZUB-015: Shock absorbers for 100 km/h speed – 349 EUR
• PTZUB-009: Running hours counter – 329 EUR
• PTO shaft complete 1⅜/6Z - 1¾/6Z (Bandioli or Waltersheiden) – 1399 EUR incl. VAT (for trailer)
• Calibration, 1-day registration in Germany, TÜV, and lights – 949 EUR
