Marine inboard engine diagnostic tool Jaltest PC Link
Marine inboard engine diagnostic tool Jaltest PC Link

Marine inboard engine diagnostic tool Jaltest PC Link

  • SKU: BD25100-2
2,799.00 €

Prices shown include tax

Send Message

Description

Marine Inboard Engine Diagnostic Tool Jaltest PC Link
Diagnostic equipment for efficient servicing of all types of marine inboard engines.

Garantinis laikotarpis - 24 mėnesiai

Professional equipment designed for precise diagnostics of electrical and electronic systems in vessels with inboard combustion engines.

Jaltest PC Link is a high-end diagnostic device developed for service professionals working with inboard engines in marine transport. Combining reliable performance, wide manufacturer coverage, and universal connectors, this tool enables comprehensive diagnostics – from fault code reading to ECU testing. It's a perfect fit for workshops looking to improve service efficiency and expand their range of offerings.



Why Choose Jaltest PC Link?
  • Diagnostics for over 99.5% of vessel models
  • One tool for a wide variety of boats and vessels – no need for separate devices.
  • Not limited to marine transport
  • Also suitable for diagnostics on trucks, buses, trailers, agricultural and construction machinery – a multifunctional tool for multiple tasks.
  • Software updated three times a year
  • An ever-expanding database ensures compatibility with the latest models and technologies.
  • Flexible connectivity – USB or Bluetooth
  • Convenient use both in the workshop and on-site – up to 50 meters of wireless range.
  • Universal cables and adapters
  • Simple connection to various systems – faster operations with fewer interruptions.
  • Rugged, reliable housing
  • Shock-resistant and ready for demanding environments – built to last.
Jaltest Marine Diagnostic Coverage:
  • Number of supported watercraft brands: 84 and growing
  • Number of supported watercraft models: 1499 and growing
  • Entries in the technical database: 2861 and growing
  • Entries in the electronic diagram database: 2137 and growing
Standard Package:
  • Jaltest Marine Inboard Software 74502003
  • Jaltest Marine Inboard License 74602003
Tester Features and Capabilities:
  • ECU diagnostics via OBD interface or specific adapter
  • Ability to connect to any diagnostic port using a universal cable with specialized connectors
  • Integrated automatic multiplexer – automatic switching of K and L, CAN, and SAE lines to any OBD terminal
  • Supported diagnostic protocols:
  • ISO 9141-2, K/L lines
  • ISO 14230 (KWP2000), K/L lines
  • SAE-J1850 VPW and PWM
  • ISO 11519-2
  • SAE J1708
  • ISO 15765-4 (OBD)
  • CAN ISO 11898
  • CAN (High Speed, Middle Speed, Low Speed, single-wire CAN systems)
  • SCI Haldex
  • RP 1210
  • SAE J2534 (PASS-THRU)
Technical Specifications:
  • Connects to desktop or laptop via Bluetooth or USB cable
  • Bluetooth range: 20–50 m
  • Minimum PC requirements: DVD drive, Windows XP, 7, 8, 10 64-bit OS, 2 GB RAM, 10 GB free hard disk space, USB port
  • Power supply via OBD connector or 12/24 V DC power adapter
  • Power consumption: 7W
  • Shock-resistant housing
  • Weight: 1.2 kg
  • Dimensions: 183 x 131 x 56 mm
  • Operating temperature: 0°C to +45°C
  • Multilingual interface
  • Certifications: CE, FCC, RoHS
Optional Accessories:
  • Cable set for cargo vessels and boat diagnostics
  • Thermoking diagnostic cable COJALI JDC113A
  • JalTest Soft + INFO Online software for diagnostics of trucks, trailers, buses, and vans
  • JalTest Soft + INFO Online 12-month update subscription
  • Software packages for trucks and tractors, buses, commercial vehicles

jaltest marine foto

Who Is This Device For?
  • JalTest PC Link is an ideal solution for workshops, independent technicians, and maintenance professionals working with vessels, boats, and marine vehicles equipped with inboard engines. It is a perfect choice for those looking to expand their technical service capabilities and work with multi-brand systems.
Become a Trusted Partner in Marine Equipment Maintenance!
Contact us today and get a personalized offer for your workshop — expand your capabilities with JalTest PC Link!
