Laser Marking Machine for Metals and Ceramics LMM30W_230V

Laser Marking Machine for Metals and Ceramics LMM30W

Country of Origin: Austria, warranty period - 24 months

The HOLZMANN laser marking machine is designed for fast and precise marking of metals, ceramics, and coated metal surfaces. This device ensures accurate performance and is suitable for both stationary and mobile use due to its adjustable design and wheels.

Features:

• Work surface with adjustable stops (using a hole pattern).
• Removable laser head for direct work on the workpiece.
• Column with manual height adjustment for positioning the laser head.
• Suitable for mobile and stationary use (wheels and feet).
• Includes: computer, monitor, keyboard, mouse, foot pedal.

Technical Specifications:

Laser Data:

• Laser: 30 W fiber laser.
• Cooling: air-cooled.

Working Parameters:

• Working area: 110 x 110 mm.
• Marking speed: < 7000 mm/s.
• Repeat accuracy: 0.003 mm.
• Total power: < 350 W.

Motor Data:

• Voltage: 230 V / 50 Hz.

Weight:

• Net weight: 67 kg.
• Gross weight: 108 kg.

Packaging:

• Packaging width (mm): 780.
• Packaging length (mm): 895.
• Packaging height (mm): 1190.
