Inverter electrode welding machine 200A Valkenpower

Inverter electrode welding machine 200A Valkenpower

By registering the equipment on the website www.soldatech-welding.com, you can extend the warranty period up to 5 years.

Functions:

• MMA (electrode) and Lift TIG welding
• Hot-start function
• Anti-stick function
• ARC force function
• Integrated overheating protection and cooling fan
• Suitable for rutile (E 6013) and basic (E 7018) electrodes
• Modern IGBT inverter technology

Technical specifications:

• Input voltage: 230 V, 1 phase
• Frequency: 50/60 Hz
• Circuit breaker: 16A C type
• Input power: 8.8 kVA
• No-load voltage: 82 V
• Duty cycle at 20°C: 40% - 200 A
• Duty cycle at 40°C: 15% - 200 A
• Welding current range: MMA 41–200 A / TIG 15–200 A
• Electrode diameter: 1.6 – 4.0 mm
• Protection class: IP21S

Product dimensions:

• Length: 400 mm
• Width: 154 mm
• Height: 300 mm
• Weight: 5.8 kg

Package dimensions:

• Length: 530 mm
• Width: 185 mm
• Height: 415 mm
• Weight: 10.60 kg

Scope of delivery:

• Twistlock electrode holder with 3 m 16 mm² cable
• Ground clamp with 2 m 16 mm² cable
• Power cable 2 m (3x2.5 mm²)
• 13 mm European-style dinse connectors
• Durable transport case
