Diesel generator Arken ARK-B2100 N5

Diesel generator Arken ARK-B2100 N5

Manufacturer: Arken, Turkey. Warranty: 1 year or 1000 working hours.

Arken is a company founded in 2012 with the motto "Life goes on". Arken generators have the ability to produce the required diesel generator according to individual needs, with a power from 2 kVA to 2750 kVA. These generators are manufactured in an area of 14000 m2 in Arnavutköy and can offer the best generator solutions according to customer or project requirements. In addition to its central factory, Arken has a very wide, global network, where it realizes its production generators and other energy solutions.

"Baudouin" is one of the brands known as reliable manufacturers of marine engines. It is a preferred brand due to its well-earned durability, high functional quality and principle of operation. The Baudouin brand, which has become one of the world-class brands, has been manufactured according to marine standards for the most suitable function. For this reason, it is known as one of the brands at the top of the list for meeting environmental standards in the marine field. These engines, which are manufactured to marine standards, are designed to be very safe, ensure the highest quality and purposeful design. The Baudouin motor is the safest motor choice, according to its operating principle, suitable for a wide range of areas. All components related to engine production are prepared using the latest technology tools.

Technical parameters:

• Generated instantaneous electrical energy (Stand-by): 2080 kVA / 1664 kW
• Permanent electricity generated (Prime power): 1900 kVA / 1520 kW
• Electrical voltage produced: 400 V / 230 V AC
• Power factor: Cos φ 0.8

Diesel engine parameters:

• Manufacturer: Baudouin
• Engine power: 1604.4 kW
• Engine model: 16M33G2000/5
• Number of cylinders: 16 cylinders
• Number of valves: 64 valves
• Number of engine strokes: 4 strokes
• Engine speed: 1500 rpm
• Displacement: 52300 cm3
• Aspiration: forced, Turbo
• Cylinder bore x stroke: 150 x 185 mm
• Compression ratio: 15:1
• Cooling method: coolant
• Coolant system capacity: 542 l
• Generator control: electronic
• Electrical control system: 24 V DC
• Battery charging current: 55 A
• Oil capacity: 175 l
• Cooling air flow: 2340 m3/min
• Starter power: 2 x 8.5 kW
• Battery capacity: 4 x 150 Ah
• Fuel consumption with (110%) load: 446.8 l/h
• Fuel consumption with (100%) load: 401 l/h
• Fuel consumption with (75%) load: 290 l/h
• Fuel consumption with (50%) load: 194.7 l/h

Generator mechanism:

• Generator manufacturer: Nekra
• Generator model: ARK 7H
• Voltage: 400 V / 230 V
• Frequency: 50 Hz
• Number of phases: 3 phases
• Number of poles: 4 poles
• Connection type: star
• Bearings: single
• Insulation class: H
• Protection class: IP23
• Control system: self excited
• Voltage regulation: Electronic AVR
• Voltage regulation ranges: +-1%
• THD: < 5%

Control panel:

• Standards: ISO8528-4
• Protection class: IP44
• Control unit: ARK700E
• Emergency stop button
• Battery charger 5 Amp
• Generator controller
• Control relays
• Connection bus (under panel)

General information:

• Length of open generator: 5060 mm
• Open generator width: 2260 mm
• Height of open generator: 2420 mm
• Open generator fuel tank capacity: 3000 l

• Length of closed generator: 9126 mm
• Closed generator width: 2440 mm
• Closed generator height: 3000 mm *
• Closed generator fuel tank capacity: 2000 l
• * Height does not include muffler height

Additional ordered components:

• 3P electrical circuit breaker
• 3P automatic reserve activation (ATS) module

Product prices:

• Open generator: 225850.00 Eur + VAT
• Closed generator: 263100.00 Eur + VAT
