Automatic leverless tire changer BD-860 + BD-215
Automatic leverless tire changer BD-860 + BD-215
New

Automatic leverless tire changer BD-860 + BD-215

You can order installation!
  • SKU: BD70778
1,969.00 €

Prices shown include tax

Papildomai galite užsakyti:

94.99 €
129.99 €
Pneumatic impact wrench, Castex 1/2", 2230 Nm
195.30 € Tire fitting kit

Send Message

Description

Automatic Leverless Tire Changer BD-860 + BD-215

Country of origin: China, warranty period – 24 months

A leverless mounting head is included in the package with the machine.

The BD-860 + BD-215 automatic tire changer is designed for professional wheel service work, allowing for quick and reliable mounting of various types of tires. The equipment is equipped with a pneumatic system, self-centering clamps, an independent inflation mechanism, and an additional mounting arm for more complex tire mounting. Its durable construction and powerful bead breaker mechanism ensure efficient daily operation.

Functions:
  • Steel mounting head with replaceable plastic protectors
  • Self-centering clamps with two pneumatic cylinders
  • Independent inflation mechanism with pressure gauge and inflation button
  • Pneumatic head locking system with pedal and control button
  • Filter and pressure regulator system
  • Auxiliary mounting arm with bead pressing rollers, lifting disc, and pressing head
Technical specifications:
  • Internal rim clamping diameter: 15" – 28"
  • External rim clamping diameter: 13" – 26"
  • Maximum wheel diameter: 1200 mm
  • Maximum wheel width: 3" – 15" (76 – 380 mm)
  • Bead breaking force: 2700 kg (27000 N)
  • Working pressure: 8 – 10 bar
  • Mounting speeds: two
  • Motor power: 1 kW
  • Power supply: 380 V / 50 Hz / 3-phase
Standard equipment:
  • Tire mounting paste bucket – 1 pc
  • Tire paste brush – 1 pc
  • Plastic protector for mounting finger – 1 pc
  • Plastic protector for bead breaker blade – 1 pc
  • Plastic protectors for clamps – 4 pcs
  • Tire lever / bar – 1 pc
