Vacuum sandblasting system Airblast AB-1050 EP / PN (dust-free)

Vacuum sandblasting system Airblast AB-1050 EP / PN (dust-free)

Fully pneumatic sanding unit, with an average sanding width of 28-32 mm, similar to electro-pneumatic versions. It is more often used for thick welds, axles, cylindrical shafts, sandblasting of large machine parts, before inspection or repair, in shipbuilding, railway industry, in the field of engines, in the structure of car bodies and trailers, containers, tanks. Due to the fact that this unit does not require power supply, this unit is ideal for mobile work, small sandblasting tasks or large, graffiti removal from building walls. Electro-pneumatic or fully pneumatic mode of operation is possible.

Functionality:

One device for everything, including automatic dust extraction and an abrasive reuse system.

Quick-change sandblasting nozzle for sandblasting different surfaces.

Fully pneumatic.

Allows sanding from low to high pressure: from 1 to 7 bar.

Maximum hose length: 5 meters

Easy principle of operation

Can be incorporated into automatic, linear sandblasting.

Advantages:

Completely dust-free and environmentally friendly sanding

Other workstations may be located near the sandblasting workstation.

Zero dust dispersion in the workplace.

Many common shapes can be scraped off without much hassle.

Low labor costs due to reusable abrasive.

Flexible and versatile equipment.

Abrasive type

Surface quality is achieved

Average amount of work performed

Steel surface

Rusted steel, primed, lightly coated surface

Alumina, garnet

SA 2 ½ (SP10)

1.2 - 1.5 m2 / h.

Heavy steel, high coatings

Alumina, garnet

SA 2 ½ (SP10)

0.5 - 1 m2 / h.

Sandblasting of steel welds

Alumina, garnet

SA 2 ½ (SP10)

50 - 60 m / h.

Polishing of stainless steel welds

Glass beads

Polishing

40 - 50 m / h.

Concrete surface

Bricks, natural stone. Cement mix, light coating or graphite removal

Alumina, olive sand

Cleaning

1.5 - 2 m2 / h

Removal of thick layers

Alumina, garnet

Paint layer removal

0.5 - 2 m2 / h

Damage-free cleaning

Olive sand, a mixture of nut shells

Cleaning

1 - 2 m2 / h

Technical data:

Working principle Electro-pneumatic Pneumatic

Abrasive capacity 28 l 28 l

Maximum hose length 5 m 5 m

Empty weight 70 kg 68 kg

Dimensions (Width x Length x Height)

53 x 61 x 132 cm

53 x 61 x 140 cm

Maximum working pressure

7 bar

7 bar

Recommended airflow

1600 l / min

3500 l / min

Electric power

3000 W

Power supply

230 V

Average sanding area

28 - 32 mm

28 - 32 mm

Maximum abrasion size

1.2 mm

1.2 mm

The AB-1050 kit includes:

Full sandblasting plant

5 m sanding hose with sandblasting nozzle and 12 mm BC nozzle.

Sand supply hose

2 ”vacuum hose

Air connection

3 standard brushes (flat brush, 90 ° inner and outer angle brush)

Instructions for use, in English.

Shipping package.

Additional accessories:

Pneumatic filter cleaning system. Special shaped brushes.
