V-Tech VT-2 Modular Power Test Bench

This model is the basic power test bench that the equipment manufacturer can offer. The single-axis measuring bench provides an opportunity to measure the power and torque of cars using the inertial method. The stand can be installed mobile or sunk into the pit, as well as providing an opportunity to improve it, expand the possibility of performing power measurement work for cars with two drive axles.

Technical data:

• Stand type: Inertial
• Dimensions: 1150 x 2740 mm
• Maximum / minimum wheelbase: 2200 / 900 mm
• Minimum tire diameter: 400 mm
• Maximum axle weight: 3000 kg
• Number of axes to be measured: 1 axis
• Braking: option to install additionally
• Maximum speed, Vmax: 300 km/h
• Measurement method: inertial
• Maximum measured power, Pmax: 450 HP*
• Power measurement accuracy: 0.1%
• Supply voltage (without cooling and exhaust fans): AC 230 V
• Compressed air required: minimum 6 bar
• Installation: mobile / buried in the pit

* Cars with higher engine power can also be tested with this stand, only the measurement accuracy will be lower. The maximum power depends on the torque characteristic of the internal combustion engine and its revolutions.

Optional extras:

• Mobile installation kit
• Cooling fan (20700 m3/h)
• Exhaust gas extraction fan (3700 m3/h)
• Additional data collection sensors (8 analog readings)
• Turbine pressure sensor (6 bar)
• Temperature sensor
• EOBD adapter
• Exhaust gas pipe (500°C)
• Exhaust gas collection nozzle (set for two mufflers)
