Two-column lift ATH-Comfort 2.40XL, Germany

Two-column lift ATH-Comfort 2.40XL, Germany

Country of origin: ATH-Heinl (Germany); Warranty 36 months

Description:

• High quality, robust electro-hydraulic two-column lift.
• Two control panels for convenient and flexible control on both columns (in the Energy-set control panel).
• High-power hydraulics ensure fast lifting and lowering.
• Asymmetrical (short to long) or symmetrical (long to long) multifunctional mounting via telescopic supports (short or long supports available as accessories).
• The electromagnetic safety interlock locks automatically when the vehicle is raised and lowered.

Technical data:

• Drive voltage (electrical): 3/400 V / 50 Hz
• Lifting capacity: 4000 kg
• Concrete strength: C20 / 25
• Width: 2500 mm
• Base thickness without floor covering: 200 mm
• Overall width: 3542 mm
• Raising / lowering time approx .: 30 S
• Max. Lifting height: 2000 mm
• Engine power: 3.0 kW
