Two-column lift ATH-Comfort 2.40XL, Germany

Two-post lift ATH-Comfort 2.40XL

Country of origin: Germany, warranty period – 24 months

Professional electrohydraulic two-post lift with two control panels for convenient operation from both sides. The robust construction and powerful hydraulic system ensure fast and smooth lifting and lowering. Asymmetric or symmetric installation is available with various lengths of telescopic arms. Electromagnetic safety unlocking automatically activates during lifting for safe operation.

Functions:

• Two control panels on both columns (Energy-set)
• Fast lifting and lowering with high-power hydraulics
• Asymmetric or symmetric installation with telescopic arms
• Electromagnetic safety unlocking
• Durable and long-lasting construction

Technical specifications:

• Lifting capacity: 4000 kg
• Maximum lifting height: 2000 mm
• Power supply: 3 / 400 V / 50 Hz
• Drive-through width: 2500 mm
• Total width: 3542 mm
• Required concrete thickness: 200 mm
• Required concrete strength: C20 / 25
• Lifting / lowering time: approx. 30 s
• Motor power: 3.0 kW
