TIG welding machine WIN TIG DC 340 T CEBORA
TIG welding machine WIN TIG DC 340 T CEBORA
New

TIG welding machine WIN TIG DC 340 T CEBORA

  • SKU: BD70760
6,129.99 €

Prices shown include tax

Send Message

Description

TIG welding machine WIN TIG DC 340 T CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below!

WIN TIG DC 340 T is a three-phase pulsed TIG and MMA welding machine with inverter technology, designed for professional use in industrial applications. This model supports only 400 V input voltage, offers high power output, electronic current control, and an exceptionally high duty cycle, making it ideal for intensive welding tasks in manufacturing, metal fabrication, shipbuilding, and other sectors where reliable and precise welding is required. It comes with a trolley but without a cooling unit, torch, or cables. Compliant with Industry 4.0 standards – featuring integrated hardware and software.

Functions:
  • TIG and MMA pulsed welding in a single device
  • High-frequency arc ignition
  • Electronic current adjustment
  • Integrated Industry 4.0 hardware and software
  • High power and excellent duty cycle even at high amperage
  • Supplied with transportation trolley
Technical specifications:
  • Power supply: three-phase, 400 V ±15%, 50/60 Hz
  • Fuse: 16 A, slow-blow
  • Power in TIG mode: 10 kVA 40%, 8.3 kVA 60%, 7.1 kVA 100%
  • Power in MMA mode: 9.8 kVA 40%, 9.2 kVA 60%, 8.7 kVA 100%
Current adjustment range:
  • TIG: 3–340 A
  • MMA: 10–270 A
Duty cycle (10 min at 40 °C):
  • TIG: 300 A 40%, 270 A 60%, 250 A 100%
  • MMA: 270 A 40%, 250 A 60%, 240 A 100%
  • Current control: electronic
  • Protection class: IP23 S
  • Weight: 53 kg
  • Dimensions (LxWxH): 410 x 610 x 810 mm
Available accessories:
5 m extension cable for remote control
  • Additional cable to increase the range of the remote control unit.
Foot pedal for welding current control
  • Pedal with a 5 m cable and ON/OFF switch, allowing convenient current regulation during welding.
Adapter for connecting torch and foot pedal
  • Designed to connect the TIG torch and pedal simultaneously to the same device.
Work return cable (3.5 m – 50 mm²)
  • Main cable with ground clamp for connecting to the workpiece.
Flowmeter with two pressure gauges
  • Device for monitoring and regulating gas flow and pressure during TIG welding.
Remote control panel
  • Allows welding parameters to be adjusted remotely.
5 m connection cable between generator and control panel
  • Cable for connecting the welding unit to the control panel at a distance of up to 5 meters.
10 m connection cable between generator and control panel
  • Same as above, but allows connection up to 10 meters.
Calibration certificate
  • Welding machine calibration certificate, valid for one year from the date of issue. Must be ordered together with the device.
