TIG welding machine WIN TIG AC-DC 270 T CEBORA

TIG welding machine WIN TIG AC-DC 270 T CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below!

WIN TIG AC-DC 270 T is a three-phase TIG and MMA welding machine with pulsed mode, high-frequency arc ignition, and advanced inverter technology. The unit is equipped with a 7-inch touch screen, transport trolley, and cooling unit. It is designed for professional use in industry, manufacturing, agriculture, road construction, and energy sectors. Due to its capabilities and functionality, it is ideal for welding aluminum, stainless steel, and other non-ferrous metals.

Functions:

• 7-inch touch screen
• Supplied with transport trolley and cooling unit
• EVO LIFT – precise electrode positioning without oxidation or thermal deformation
• EVO START – optimized arc ignition at the edges
• APC TIG – deeper penetration, more stable arc, anti-stick protection
• Pulsed welding up to 2.5 kHz
• eXtra Pulse (XP) – high-frequency pulses for thin metal sheet welding
• Low-frequency pulses usable with XP function
• JOB function – allows storing up to 99 programs
• Minimum current level in DC mode – 3 A
• AC TIG – waveform width and duration adjustment
• AC+DC TIG – welding aluminum and its alloys
• AC frequency: 50–200 Hz
• 3 waveform types: square, triangular, sinusoidal
• AC MMA – suitable for use with magnetized metal sheets
• VRD function – for safe use in hazardous environments
• Industry 4.0 – compatible with LAN, Wi-Fi, remote diagnostics
• 2 USB ports for data download and updates
• Digital ammeter/voltmeter with 1% accuracy and thermal protection

Technical specifications:

• Power supply: three-phase, 400 V ±15%, 50/60 Hz
• Fuse: 10 A, slow-blow
• Power in TIG mode: 7.6 kVA 40%, 7.1 kVA 60%, 6.3 kVA 100%
• Power in MMA mode: 8.0 kVA 40%, 7.4 kVA 60%, 7.0 kVA 100%

Current adjustment range:

• TIG: 3–270 A
• MMA: 10–210 A

Duty cycle (10 min at 40 °C):

• TIG: 270 A 40%, 250 A 60%, 230 A 100%
• MMA: 210 A 40%, 200 A 60%, 190 A 100%
• Protection class: IP23S
• Weight: 69 kg
• Dimensions (LxWxH): 560 x 950 x 1010 mm

Available accessories:

• 5 m extension cable for remote control
• Foot pedal for current adjustment with 5 m cable and ON/OFF switch
• Adapter for simultaneous connection of torch and pedal
• Work return cable (3.5 m – 50 mm²)
• Flowmeter with two pressure gauges
• Remote control panel
• 5 m connection cable between the unit and control panel
• 10 m connection cable between the unit and control panel
• Calibration certificate (valid for 1 year from the date of issue)
