Smoke generator Autool SDT206

Smoke generator Autool SDT206

This Autool SDT206 smoke generator is a high-class car leak test mechanism. It has stable performance with two testing systems, air blowing and smoke generation. It has a built-in powerful air compressor, so you don't need to buy any additional air sources and you will have fewer unnecessary air hoses when working with the device. A clear and easy-to-understand oil level scale that allows you to effectively monitor the oil level and cleanliness in the tank. Thanks to the adjustable air flow, you can properly adjust, adjust the most suitable smoke flow for you, according to your individual needs. And the pressure manometer used allows for faster identification and detection of various leaks.

Features:

• Integrated air compressor
• Two modes: air and smoke blowing
• External pressure gauge
• Protection against overheating or freezing
• A wide range of application possibilities
• Rapid puffing of smoke
• Compact and mobile design
• Adjustable air flow

Performing a leak test:

1. Add approximately 10-15ml of test oil directly into the oil reservoir of the smoke generator. Place or hang the smoke generator securely so that it is ready for use
2. Disconnect the hose or open the covers of any system you are about to test
3. Connect the smoke generator to the vehicle's 12V battery, turn it on and it will start working immediately
4. After about 30 seconds, the system you are testing will be filled with smoke. Then you can consistently inspect the vehicle's systems and assess whether there are any leaks

Main components of the device:

• Pressure gauge
• Air flow pressure gauge
• Flow control valve
• Oil filler hole
• Oil level scale
• Oil outlet

Technical parameters:

• Outlet pressure: <18 psi ~ 1.25 bar
• Output flow: 6 l/min
• Air compressor: integrated
• Power supply: 12 V / DC
• Operating temperature: from -20 °C to +75 °C
• Dimensions: 275 x 150 x 150 mm
• Weight: ~5.5 kg
• Package dimensions: 270 x 220 x 255 mm

The set includes:

• 1 x Smoke generator Autool SDT206
• 1 x Hook
• 1 x Rubber connection adapters
• 1 x Standard Cone and Rubber Adapter
• 1 x Universal Inflatable Seal Pump
• 1 x Power cords
• 1 x Special valve key
• 1 x Test Oil Filling Bottle
• 1 x Special EVAP system adapter
• 1 x Smoke Hose
• 1 x User manual
