Refrigerant R-1234yf composition identifier BD86
Refrigerant R-1234yf composition identifier BD86
Refrigerant R-1234yf composition identifier BD86
Refrigerant R-1234yf composition identifier BD86
Refrigerant R-1234yf composition identifier BD86

Refrigerant R-1234yf composition identifier BD86

  • SKU: BD16987
1,270.00 €

Prices shown include tax

Send Message

Description

Refrigerant R-1234yf composition identifier BD86
Country of origin: China, warranty period - 24 months

The BD86 is an intelligent and high-precision air conditioning system diagnostic device designed for vehicles using R-1234yf refrigerant. It combines refrigerant identification, pressure measurement, ambient temperature and humidity analysis, outlet air temperature monitoring, and advanced NDIR leak detection technology. The BD86 enables comprehensive A/C system testing and generates a professional digital report, helping service centers inform customers about the real condition of their system.



Functions:
  • Refrigerant identification in vehicles or refrigerant containers
  • Wireless outlet air temperature sensor (Wi-Fi connection, battery-powered)
  • Comprehensive A/C system diagnostics with a digital report for the customer
  • NDIR leak detection – accuracy up to 5 g/year within 10–15 minutes
  • Ambient temperature and humidity analysis
  • Automatic pressure and temperature measurement and analysis
Technical specifications:
  • Power supply: 230 V / 50 Hz / 1 phase or 12 V DC
  • Refrigerant identification accuracy: 0.1%
  • Identification time: 120 sec
  • Recommended ambient temperature range: 20 – 50 °C
  • Working pressure: from -1 to 30 bar
  • Pressure measurement accuracy: ± 0.1 bar
  • Outlet air temperature range: 0 – 100 °C
  • Outlet air temperature accuracy: ± 0.1 °C
  • Leak detection sensitivity: 5 g/year
  • Total testing time: 6 min
  • Estimated leak detection time per vehicle: 10–15 min
  • Refrigerant type: R-1234yf
  • Weight: 9.9 kg
  • Dimensions: 410 x 383 x 280 mm
  • Package dimensions: 475 x 440 x 345 mm
