Professional diagnostic tool AUTEL MaxiDiag MD909 Pro

Professional Diagnostic Tool AUTEL MaxiDiag MD909 Pro

A universal solution for car workshops and independent diagnostics specialists.

Country of origin: Germany, warranty period – 24 months

The MaxiDiag MD909 Pro is a professional handheld diagnostic tool designed for advanced and fast full-system vehicle diagnostics. The device is equipped with the latest technology, allowing access to all control modules and performing essential maintenance functions including oil reset, brake bleeding, battery, and DPF system services. It features an intuitive user interface, wide vehicle coverage, and updatable software.

Why choose the MaxiDiag MD909 Pro?

• Full system diagnostics – detects faults in all modules, reads and clears trouble codes, and displays live data
• 11 professional service functions – from oil reset to brake bleeding or DPF regeneration
• Bluetooth VCI connectivity – enables convenient handheld operation without cable restrictions
• CAN FD protocol support – compatible with the latest-generation vehicles
• Access to manufacturers’ security gateways – work with FCA, SFD, and other secure vehicle systems
• Powerful battery and Android platform – smooth performance, long runtime, familiar interface
• Lifetime OTA updates – free software updates for the entire device usage period

Functions:

• Extensive and current year vehicle coverage from U.S., Asian, and European manufacturers, access to all modules in all systems
• Enhanced Mode 6 diagnostics, full system AutoScan DTCs detection, reads & clears codes, views live and freeze frame data
• 11 service functions: oil reset (OIL RESET), brake bleeding (BREAK BLEEDING), injector (INJECTOR), steering angle sensor (SAS), throttle (THROTTLE), electronic parking brake (EPB), battery management system (BMS), tire pressure monitoring system (TPMS), diesel particulate filter (DPF), AFS headlamp (AFS Headlamp), air/fuel ratio (A/F)
• Support for all OBDII protocols and 10 OBDII test modes, I/M readiness and emissions test function
• 5.5-inch screen, 64 GB memory, Android system, user-friendly interface
• 5000 mAh battery – long operating time
• Bluetooth VCI connection – more convenient handheld use
• CAN FD protocol support – compatibility with advanced systems
• Security gateway access – FCA, SFD, etc.
• Expandable battery testing function (BT506 required)
• Free lifetime OTA software updates

*For more details on gateway availability, please contact your local distributor

Technical specifications:

• VCI: V150 Lite
• Operating system: Android 9
• Battery: 5000 mAh
• Memory: 64 GB
• Screen: 5.5-inch
• Vehicle coverage: latest year vehicles from Asia, Europe, America, and China
• System coverage: all
• Code reading/clearing:
• Live data:
• Security gateways: FCA, SFD, etc.
• Service functions:
• Oil reset (OIL RESET)
• Brake bleeding (BREAK BLEEDING)
• Injector programming (INJECTOR)
• Steering angle sensor calibration (SAS)
• Throttle adaptation (THROTTLE)
• Electronic parking brake control (EPB)
• Battery management system reset (BMS)
• Tire pressure monitoring system (TPMS)
• Diesel particulate filter regeneration (DPF)
• Adaptive front-light system configuration (AFS Headlamp)
• Air-fuel ratio adaptation (A/F)
• Extension: battery test (BT506 required)
• Communication protocol: CAN FD
• Software: free updates for the lifetime of the device

Who is this tool for?

• The MaxiDiag MD909 Pro is perfect for automotive service shops, independent diagnostic technicians, and maintenance professionals who need a mobile, intelligent, and powerful full-system diagnostic solution. It is a cost-effective tool for both daily tasks and advanced operations.
