Pneumatic-hydraulic jack AC Hydraulic 25-2

Pneumatic-hydraulic jack AC Hydraulic 25-2
Pneumatic-hydraulic jack AC Hydraulic 25-2
Pre-order
2,178.00€
Ex Tax: 1,800.00€
Prices include VAT
Want to buy or learn more?

Fill out the inquiry form

Pneumatic-hydraulic jack AC Hydraulic 25-2


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Robust two-step pneumatic-hydraulic jack for buses and trucks

Description:

- Minimum height of 180 mm
- Designed for heavy, heavy commercial use
- Solid chrome plated cylinder for durability
- Integrated safety relief valve
- Manual emergency control for optimum safety during lifting and lowering
- Supplied with two extensions (50/100 mm)
- Ergonomic handle with control buttons
- Warranty: 3 years

Technical parameters:

- Lifting capacity: 25/10 tonnes
- Minimum height: 180 mm
- Maximum height: 275/380 mm
- Body length: 770 mm
- Handle length: 1160 mm
- Width: 160 mm
- Width (with wheels): 305 mm
- Required compressed air pressure: 9 - 12 bar
- Required compressed air flow: 350 L / min
- Weight: 60 kg

Additional equipment:

- F250: extension, 250 mm
- FW: nozzle for bolting and so on.
- FW1: nozzle for lifting under various axles
