Plasma cutter PLASMA SOUND PC 130/T CEBORA

Plasma cutter PLASMA SOUND PC 130/T CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below!

PLASMA SOUND PC 130/T is a three-phase inverter-type plasma cutting machine with advanced “On Air” ignition technology, designed for professional and intensive metal cutting. It features a very wide current adjustment range, the ability to cut steel up to 60 mm thick, a high duty cycle, and excellent cutting precision. Perfectly suited for both manual and automated (CNC) cutting in metal processing, industrial, and maintenance applications.

Functions:

• Three-phase device with wide voltage support (208–440 V)
• “On Air” ignition – ensures smooth and quick arc ignition
• Electronic, stepless current adjustment
• High duty cycle even at maximum current
• Wide current adjustment range – from 20 to 130 A
• Compatible with 6 m or 15 m torches
• Suitable for both manual and CNC cutting
• Highly reliable and robust housing

Technical specifications:

• Power supply: 208/220/230 V ±10% and 400/440 V ±10%, 50/60 Hz, three-phase
• Fuse: 50 A (230 V), 32 A (400 V), slow-blow
• Power: 22 kVA 50%, 21 kVA 60%, 16.6 kVA 100% (230 V); 22 kVA 60%, 21 kVA 100% (400 V)
• Current adjustment range: 20–130 A
• Duty cycle (10 min at 40 °C): 130 A 50%, 125 A 60%, 105 A 100%
• Cutting thickness on steel: recommended – 40 mm, maximum – 60 mm (2"–2 1/4")
• Torch length: 6 m or 15 m
• Air consumption: 250 l/min at 5.5 bar
• Adjustment: Electronic, stepless
• Protection class: IP23S
• Weight: 50 kg
• Dimensions (LxWxH): 297 x 613 x 558 mm

Available accessories:

• Hand torch – CEBORA CP 162C MAR 6 m
• Hand torch – CEBORA CP 162C MAR 15 m
• Machine torch for CNC cutting – CEBORA CP 162C DAR 6 m
• Machine torch for CNC cutting – CEBORA CP 162C DAR 15 m

DAR-type torches must be used with a control module!
