Planer-thicknesser Holzmann HOB305PROSMW2

Planer-thicknesser Holzmann HOB305PROSMW2

Country of origin: Germany, warranty period - 24 months

Note: Available in 400V or 230V versions

The Holzmann HOB305PROSMW2 planer-thicknesser is professional woodworking equipment with a spiral cutter head, designed for precise and high-quality planing and thicknessing. The carbide inserts ensure long service life and excellent processing results, while the precise central height adjustment allows convenient work with workpieces of various thicknesses. Due to its robust construction and high manufacturing quality, this machine is ideal for professional workshops.

Functions:

• Spiral cutter head with 24 carbide inserts – optimal processing results
• Square inserts can be used four times (15 x 15 x 2.5 mm, 30°)
• Smooth central height adjustment of the thicknessing table
• Both cast iron tables can be folded up when switching to thicknessing mode
• Advanced manufacturing technologies used, such as laser cutting
• Maximum planing width: 304 mm, maximum thicknessing width: 300 mm
• Included: fence, pre-installed carbide inserts, wrench for insert replacement

Technical specifications:

• Planing table dimensions: 1512 x 400 mm
• Thicknessing table dimensions: 585 x 300 mm
• Thicknessing table height: 901 mm
• Maximum cutting depth (planing and thicknessing): 3 mm
• Maximum workpiece height: 225 mm
• Planing fence dimensions: 100 x 160 mm
• Fence tilt: 90°–45°
• Cutter block diameter: 74 mm
• Cutter block speed: 4000 rpm
• Number of inserts: 24
• Feed speed: 5.5 m/min
• Motor power (S1): 2200 W
• Voltage: 230 V / 50 Hz
• Dust extraction port diameter: 100 mm
• Overall dimensions: 1665 x 575 x 930 mm
• Net weight: 258 kg
• Gross weight: 292 kg
• Packaging dimensions: 1650 x 650 x 1150 mm (L x W x H)
