Paint mixing room BD-PT4

Paint mixing room BD-PT4

Country of origin: China, warranty period - 24 months

The paint mixing room BD-PT4 is the largest model in this series, designed for intensive and safe paint preparation in vehicle painting processes. The structure is made of colored steel panels with EPS filling, providing thermal and sound insulation. Convenient access is ensured through large aluminum doors with a tempered glass window, while a reliable ventilation and lighting system allows for efficient and safe operation.

Functions:

• Large aluminum doors with tempered glass observation window
• Highly efficient air volume – 2800 m³/h
• Low noise level – less than 80 dB
• Ceiling-mounted lighting with 10 explosion-proof LED lamps
• High-quality two-stage air filtration system
• Thick walls with excellent thermal and sound insulation properties
• Control system: lighting, fan, power socket

Technical specifications:

• Internal dimensions: 5680×3480×2500 mm (L×W×H)
• External dimensions: 5780×3580×2550 mm (L×W×H)
• Airflow: 2800 m³/h
• Filter efficiency: ≥85 %
• Lighting: 5 groups of 2 units, total 10 x 24W explosion-proof LED lamps
• Noise level: <80 dB
• Working gate: 650×2000 mm
• Wall thickness: 0.45 mm steel with 50 mm EPS filling
• Filter system: primary filter (G2) >83 %, exhaust filter >70 %
• Total power: 0.7 KW
• Control system: lighting, fan, power socket
