Paint mixing room BD-PT1

Paint mixing room BD-PT1

Country of origin: China, warranty period - 24 months

The paint mixing room BD-PT1 is designed for safe and high-quality automotive paint mixing, ensuring clean air, proper lighting, and noise control. The structure is made of colored steel panels with EPS filling, and the door features a tempered glass observation window and strong aluminum frame for convenient and safe use.

Functions:

• High-strength aluminum door with tempered glass observation window
• Comfortable operation with low noise level (<80 dB)
• Efficient ventilation with axial fan
• Ceiling-mounted LED lighting with explosion-proof lamps
• Two-stage air filtration system
• Suitable for paint mixing and hazardous fume extraction
• Easy control – lighting, fan, and power socket

Technical specifications:

• Internal dimensions: 2230×3480×2500 mm (L×W×H)
• External dimensions: 2330×3580×2550 mm (L×W×H)
• Airflow: 2800 m³/h
• Filter efficiency: ≥85 %
• Lighting: 2 groups of 2 units, total 4 x 24W explosion-proof LED lamps
• Noise level: <80 dB
• Working gate: 650×2000 mm
• Wall thickness: 0.45 mm steel with 50 mm EPS filling
• Filter system: primary filter (G2) >83 %, exhaust filter >70 %
• Total power: 0.5 KW
• Control system: lighting, fan, power socket
