Multifunctional cutting and milling machine Holzmann KF315VF2600

Multifunctional Cutting and Milling Machine Holzmann KF315VF2600

Country of origin: Austria, warranty period - 24 months

Note: may be 400V or 230V

The Holzmann KF315VF2600 is a high-quality multifunctional machine that combines circular saw and milling operations. Thanks to its solid cast iron table, large cutting area, and adjustable settings, this machine is perfectly suited for cutting large-size panels and complex milling tasks. Convenient controls, electronic speed display, and precise guides ensure efficient and safe operation for both professionals and advanced users.

Features:

• Sturdy, smooth-running fence guide with quick locking clamp
• Tiltable and height-adjustable circular saw blade with scoring unit
• Cast iron worktable with rear and side extensions and support leg
• Retractable mitre fence with end stop
• Support roller on outrigger table for easier material handling
• Large cutting width at the rip fence – up to 1330 mm
• Standard equipment includes a double scoring blade
• High-quality shaper hood with guides, protective plate, and adjustable aluminum fences
• Four spindle speeds ranging from 1800 to 9000 rpm
• Electronic speed display with LED screen
• Maximum tool diameter – 200 mm
• Included: scoring unit, Ø315 mm circular saw blade (40 teeth), Ø100 mm scoring blade (24 teeth), rip fence, mitre fence, angle gauge, parallel fence, telescopic fence

Technical specifications:

• Motor power S1: 3800 / 2800 W
• Voltage: 400 V
• Table dimensions: 860 x 890 mm
• Table height: 850 mm
• Table extensions: 800 x 440 / 500 x 450 mm
• Dust extraction ports: 2 x Ø100 mm
• Sliding table dimensions: 2600 x 270 mm
• Outrigger table dimensions: 750 x 590 mm
• Max. cutting height at 90°: 100 mm
• Max. cutting length: 2700 mm
• Max. cutting height at 45°: 80 mm
• Max. cutting width at the rip fence: 1330 mm
• Spindle diameter: 30 mm
• Spindle speeds: 1800 / 3000 / 6000 / 9000 rpm
• Spindle stroke: 100 mm
• Max. clamping height: 100 mm
• Max. tool diameter below table: 180 mm
• Table opening: 190 mm
• Mitre fence dimensions: 360 x 120 mm
• Max. tool diameter above table: 200 mm
• Saw blade diameter: Ø315 mm
• Scoring blade diameter: Ø100 mm
• Saw blade speed: 4500 rpm
• Scoring unit speed: 8500 rpm
