Multifunctional cutting and milling machine Holzmann KF315VF2000

Multifunctional Cutting and Milling Machine Holzmann KF315VF2000

Country of origin: Austria, warranty period - 24 months

Note: may be 400V or 230V

The Holzmann KF315VF2000 is a robust and reliable multifunctional machine that combines circular saw and milling capabilities. Thanks to its tiltable saw blade with scoring unit, large cast iron worktable with extensions, and four milling spindle speeds, this unit is perfectly suited for processing large panels in professional carpentry or furniture production.

Features:

• Sturdy and smoothly running rip fence with quick locking clamp
• Tiltable and height-adjustable circular saw blade with scoring unit
• Cast iron worktable with rear and left extensions and support leg
• Retractable mitre fence with workpiece end stop
• Support roller for easier material feed
• Large cutting width at the rip fence – up to 1330 mm
• Standard equipment includes a two-piece scoring blade
• High-quality shaper hood with guides, protective plate, and adjustable aluminum fences
• Four spindle speeds (1800–9000 rpm)
• Electronic speed display with LED screen
• Maximum tool diameter – 200 mm
• Convenient and removable spindle adjustment handwheel
• Included: scoring unit, Ø315 mm circular saw blade, Ø100 mm scoring blade, angle gauge, rip fence, telescopic fence

Technical specifications:

• Motor power S6: 5100 / 4000 W
• Motor power S1: 3800 / 2800 W
• Voltage: 400 V
• Table dimensions: 860 x 890 mm
• Table height: 850 mm
• Table extensions: 860 x 440 / 500 x 450 mm
• Dust extraction ports: 2 x Ø100 mm
• Sliding table dimensions: 2000 x 270 mm
• Outrigger table dimensions: 750 x 590 mm
• Max. cutting height at 90°: 100 mm
• Max. cutting length: 2200 mm
• Max. cutting height at 45°: 80 mm
• Max. cutting width at the rip fence: 1330 mm
• Spindle diameter: 30 mm
• Spindle speeds: 1800 / 3000 / 6000 / 9000 rpm
• Spindle stroke: 100 mm
• Max. clamping height: 100 mm
• Max. tool diameter below table: 180 mm
• Table opening: 190 mm
• Mitre fence dimensions: 360 x 120 mm
• Max. tool diameter above table: 200 mm
• Saw blade diameter: Ø315 mm
• Scoring blade diameter: Ø100 mm
• Saw blade speed: 4500 rpm
• Scoring unit speed: 8500 rpm
• Net weight: 310 kg
• Gross weight: 425 kg
• Packaging height: 1035 mm
• Packaging width: 825 mm
• Packaging length: 990 mm
