MIG/MAG pulse welding machine SYNTAR 270 T CEBORA
MIG/MAG pulse welding machine SYNTAR 270 T CEBORA
New

MIG/MAG pulse welding machine SYNTAR 270 T CEBORA

  • SKU: BD70770
3,199.00 €

Prices shown include tax

Send Message

Description

MIG/MAG pulse welding machine SYNTAR 270 T CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below and activate the impulse function!

SYNTAR 270 T is a three-phase synergic MIG/MAG pulse welding machine with an aluminum four-roller wire feed mechanism and the capability to use PULSE and DOUBLE PULSE functions. It is designed for working with various types of wire – from plain steel to stainless steel, aluminum, CuSi3%, and flux-cored. The device is ideally suited for use in the chemical and food industries, construction, metal structure fabrication, road building, tank construction, and maintenance sectors.

Functions:
  • Aluminum four-roller wire feed mechanism (Ø 30 mm)
  • 28 synergic programs (for steel and flux-cored wire)
  • More than 30 additional synergic curves (Art. 238)
  • PULSE function activation (Art. 238)
  • DOUBLE PULSE function activation (Art. 813)
  • LCD display shows wire type, gas type, current, voltage, wire speed, and material thickness
  • Adjustable parameters: arc length, 2/4 stroke, spot and pause time, inductance, burn back, soft start, etc.
  • Three automatic functions for optimal aluminum welding
  • Euro connector allows the use of a standard MIG torch or Push-Pull 2003 torch
  • Compatible with Ø 200 mm or Ø 300 mm wire spools
Technical specifications:
  • Power supply: 400 V, 50/60 Hz, +15 % / -20 %
  • Fuse: 16 A, slow-blow
  • Power: 9.3 kVA 20 %, 6.9 kVA 60 %, 5.3 kVA 100 %
  • Current adjustment range: 20 – 270 A
  • Duty cycle (10 min at 40 °C): 270 A 20 %, 220 A 60 %, 180 A 100 %
  • Regulation: electronic, stepless
  • Wire types:
  • 0.6 / 0.8 / 0.9 / 1.0 / 1.2 mm (steel)
  • 0.6 / 0.8 / 0.9 / 1.0 / 1.2 mm (aluminum)
  • 0.8 / 0.9 / 1.0 mm (stainless steel)
  • 0.8 / 0.9 / 1.0 mm (CuSi3%)
  • 0.9 mm (flux)
  • Max. spool size: Ø 300 mm / 15 kg
  • Protection class: IP23S
  • Weight: 50 kg
  • Dimensions (LxWxH): 480 x 830 x 825 mm
Available accessories:
  • CEBORA PUSH-PULL (UP/DOWN) torch
  • CEBORA 380 A water-cooled torch
  • CEBORA 280 A air-cooled MIG torch
  • GRV14 torch cooling unit
  • Gas flowmeter with 2 pressure gauges
  • Aluminum welding kit
