MIG/MAG pulse welding machine SYNTAR 200 M CEBORA
MIG/MAG pulse welding machine SYNTAR 200 M CEBORA
New

MIG/MAG pulse welding machine SYNTAR 200 M CEBORA

  • SKU: BD70769
2,499.00 €

Prices shown include tax

Send Message

Description

MIG/MAG pulse welding machine SYNTAR 200 M CEBORA

Country of origin: Italy, warranty period – 24 months

Optional accessories for this device are listed below and activate the impulse function!

SYNTAR 200 M is a single-phase synergic MIG/MAG pulse welding machine with an aluminum two-roller wire feed mechanism, designed for working with various types of wire: steel, stainless steel, aluminum, CuSi3%, and flux-cored wire. The device features integrated PULSE and DOUBLE PULSE functions, an intuitive LCD display, and a wide range of adjustable parameters, allowing for high-quality welding results. It is ideal for use in metal structure fabrication, shipbuilding, building and road construction, bodywork repair, agriculture, and workshops.

Functions:
  • Aluminum two-roller wire feed mechanism (Ø 30 mm)
  • Ground cable with clamp (3 m – 25 mm²)
  • 28 synergic programs, plus additional PULSE synergic curves (Art. 238)
  • LCD display shows real-time information on gas type, current, voltage, material thickness, and wire speed
  • Option to use PULSE and DOUBLE PULSE functions (Art. 813)
  • Control panel allows adjustment of: arc length, 2/4 stroke, spot time, pause time, inductance, burn back, etc.
  • Three automatic functions for optimal aluminum welding
  • Compatible with both MIG torches and CEBORA Push-Pull 2003 type torches
  • Compatible with Ø 200 mm or Ø 300 mm wire spools
Technical specifications:
  • Power supply: 230 V, 50/60 Hz, +15 % / -20 %
  • Fuse: 16 A, slow-blow
  • Power: 6.3 kVA 20 %, 3.8 kVA 60 %, 3.1 kVA 100 %
  • Current adjustment range: 20 – 200 A
  • Duty cycle (10 min at 40 °C): 200 A 20 %, 140 A 60 %, 120 A 100 %
  • Regulation: electronic, stepless
  • Wire types:
  • 0.6 / 0.8 / 0.9 / 1.0 mm (steel)
  • 0.6 / 0.8 / 0.9 / 1.0 / 1.2 mm (aluminum)
  • 0.8 / 0.9 / 1.0 mm (stainless steel, CuSi3%)
  • 0.9 mm (flux)
  • Max. spool size: Ø 300 mm / 15 kg
  • Protection class: IP23S
  • Weight: 45 kg
  • Dimensions (LxWxH): 480 x 830 x 825 mm
Available accessories:
  • CEBORA PUSH-PULL (UP/DOWN) torch
  • CEBORA 280 A MIG torch (air cooled)
  • Gas flowmeter with 2 pressure gauges
  • Aluminum welding kit
