Metal lathe Holzmann ED400FD

Metal lathe Holzmann ED400FD

Manufacturer: Holzmann (Austria)

Features:

CW/CCW operation mode

Powerful, low-maintenance motor with low-voltage switch

Hardened main shaft with adjustable tapered roller bearings

Smooth transmission of engine power ensures constant, even torque

Tailstock - can be adjusted for taper rotation

Directional, conveniently adjustable via V-shaped axles

Hardened and precisely ground prism guides for professional work

Complete with metal shift gears for exceptionally wide thread cutting range

The speed is adjustable gradually - the speed can be conveniently read on the digital screen

Complete set: 3-piece turning chuck Ø 100 mm, 4-way turning column, MT3 turning part, MT2 gripping point, chuck guard, chip tray, gear changing tool, other tools

Technical data:

Motor power s1: 450 W

Power supply: 230V / 50Hz

Motor power s6: 630 W

Cable length: 1.7 m

Overall dimensions: 940 x 380 x 345 mm

Lathe width: 100 mm

Shaft bore: 21 mm

Shaft taper: MK3/MT3

Tailstock taper: MK2/MT2

Max. turning on transverse turning: 134 mm

Turning speed min-1 50-2500

Metric thread range mm/r: 0.5-3 (14)

Inch Thread Range: 8-44 (10)

Tailstock travel: 55mm

Transverse feeding stroke: 80 mm

Compound turning stroke: 55 mm

Distance between centers: 400 mm

Max. space above the lathe base: 210 mm

Longitudinal feed: 0.089 / 0.147 / 0.198 mm / U

Max. tool holder cross-section: 10 mm

Net weight: 68 kg

Gross weight: 75 kg
