Magnetic drill, Fluxon 100 mm

Magnetic drill, Fluxon 100 mm

Fluxon magnetic drills are designed to provide the power and efficiency required to complete all assigned tasks. They are distinguished by their strength and quality aspects. Drilling machines are equipped with a powerful electric motor, an integrated cooling system and have a reliable and compact device design. Perfect for a variety of heavy-duty tasks that require precision and power.

Technical parameters:

• Power supply: 220 - 240 V / 50 - 60 Hz
• Stroke: 260 mm
• Rotation speed, with load: 1 speed - 85 rpm | Speed 2 - 152 rpm | Speed 3 - 270 rpm | Speed 4 - 480 rpm
• Rotation speed, no load: 1 speed - 380 rpm | Speed 2 - 690 rpm | Speed 3 - 380 rpm | Speed 4 - 610 rpm
• Annular cutters: Ø 12 – 100 mm
• Twist drills: Ø 1 – 37.75 mm
• Countersinking: Ø 1 – 105 mm
• Magnet size: 220 x 110 x 64 mm
• Magnet force: 2500 kg
• Motor power: 1800 W
• Total power: 1950 W
• Spindle (Weldon): MT3 19.05mm
• Spindle thread size: M3 - M30
• Product dimensions: 350 x 200 x 520 mm (Length x Width x Height)
• Product weight: 26.3 kg
