Electrohydraulic loader 1000 kg NH Handling SB1016E
Electrohydraulic loader 1000 kg NH Handling SB1016E

Electrohydraulic loader 1000 kg NH Handling SB1016E

  • SKU: BD99858
3,130.00 €

NH Handling NH Handling
Prices shown include tax
Add to Cart

Send Message

Description

Electro-hydraulic stacker 1000 kg NH Handling SB1016E
Country of origin: Denmark, warranty period - 36 months

NH Handling SB1016E is a reliable and compact electro-hydraulic stacker designed for efficient lifting of loads up to 1600 mm high in industrial environments. Due to its narrow turning radius, it is ideal for work in confined spaces. The stacker is equipped with single forks, a convenient control system, battery charge indicator, and parking brake, while the polyurethane rollers ensure quiet movement and protect the floor surface.

Functions:
  • Available lifting heights: 1600, 2500, or 3000 mm
  • Suitable for use in narrow and confined spaces
  • Integrated battery charge indicator
  • Equipped with a parking brake for safe operation
  • Standard polyurethane fork rollers
  • Quiet movement and floor protection thanks to polyurethane wheels
Technical specifications:
  • Maximum load capacity: 1000 kg
  • Lifting function: electro-hydraulic
  • Battery: 12 V / 150 Ah
  • Lifting height: 1600 mm
  • Fork type: single
  • Fork length: 1150 mm
  • Fork width: 550 mm
  • Steering wheel diameter: 180 x 50 mm
  • Fork wheel diameter: 74 x 70 mm
  • Wheel type: polyurethane
  • Weight: 396 kg
