Name: Electro-hydraulic press AC Hydraulic P60EH1
Brand: AC-HYDRAULIC
SKU: P60EH1
Price: 7925.50 EUR
Availability: InStock

Electro-hydraulic press AC Hydraulic P60EH1

Pre-order

7,925.50€

Ex Tax: 6,550.00€

Prices include VAT

Qty

Add to Cart

Add to Wish List

Want to buy or learn more?

Electro-hydraulic press AC Hydraulic P60EH1

AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Electro-hydraulic press for truck repair facilities and heavy industry

Description:

- P60EH1: One step pump

- P60EH2: Two-step pump

- The pressure can be set to any value up to 60 tonnes

- Sliding double action 300 mm stroke cylinder

- Integrated pressure gauge at comfortable eye level

- Gerva controlled press desk

- Integrated safety relief valve

- Removable cylinder head for adapting different heads

- Motor 3x400V 50 / 60Hz (Can be changed to 3x230V on request)

- Supplied with 2 prisms

- Manufacturer: Denmark

- Warranty: 3 years

Technical parameters:

- Capacity: 60 tonnes

- Stroke of piston: 300 mm

- Press height: 2020 mm

- Press width with motor: 1555 mm

- Inner width: 1010 mm

- Inside Depth: 260 mm

- Working area: 170 - 760 mm

- Press speed: 4.2 mm / s

- Return speed: 5.9 mm / s

- Weight: 630 kg
