Electro-hydraulic press AC Hydraulic P100EH2
Electro-hydraulic press AC Hydraulic P100EH2

Electro-hydraulic press AC Hydraulic P100EH2

  • SKU: BD13500
11,132.00 €

AC-HYDRAULIC AC-HYDRAULIC
Prices shown include tax
Add to Cart

Send Message

Description

Electro-hydraulic press AC Hydraulic P100EH2


AC-Hydraulic, Denmark; Warranty: 3 years for hydraulics and 10 years for body parts

Electro-hydraulic press for truck repair facilities and heavy industry

Description:

- Electro-hydraulic 2-step pump (press speed 6.2 mm / sec)
- The pressure can be set to any value up to 100 tonnes
- Sliding double action 300 mm stroke cylinder
- Integrated pressure gauge at comfortable eye level
- Gerva controlled press desk
- Wide welded casing and press table made of high-strength steel
- Integrated safety relief valve
- Removable cylinder head for adapting different heads
- Motor 3x400V 50 / 60Hz (Can be changed to 3x230V on request)
- Supplied with 2 prisms
- Manufacturer: Denmark
- Warranty: 3 years

Technical parameters:

- Capacity: 100 tonnes
- Stroke of piston: 300 mm
- Press height: 2040 mm
- Press width with motor: 1765 mm
- Inside width: 1100 mm
- Inside Depth: 325 mm
- Working area: 35 - 635 mm
- Press speed: 6.2 mm / s
- Return speed: 8.3 mm / s
- Weight: 1215 kg
