DPF filter cleaning machine brown B02PLUS

DPF Filter Cleaning Machine Brown B02PLUS

Functions:

• Advanced technology: The combination of water flushing and high-pressure air purging processes effectively removes even the toughest blockages.
• Wide application: Suitable for cleaning various sizes of DPF, SCR, and catalytic converters.
• Water heating function: Maintains a constant temperature (60–80°C) to ensure effective cleaning.
• Pressure testing function: Allows for checking the DPF blockage level before and after the cleaning cycle.
• Air drying system: Ensures quick drying of the filter after cleaning.
• Intelligent control system: Features a PLC controller with a touchscreen, enabling the regulation of temperature, pressure, and cleaning time.
• Water filtration system: Ensures an extended water cycle usage.
• Fast operation: The complete regeneration process takes only 30–60 minutes.
• Multi-layered safety system: Includes liquid level alarms, temperature control, sealing inspection, leakage protection, and built-in lighting features.

Technical Specifications:

• Model: BR-SCR / DPF B02 Plus
• Weight: 400 kg
• Dimensions: 1400 mm x 800 mm x 1710 mm
• Voltage: 380V, 50Hz
• Cleaning flow rate: 10 m³/h
• Explosion pressure: 0.01–0.2 MPa
• Wind pressure detection: 0–0.3 kPa
• Air volume: 320 m³/h
• Working filters: DPF, DOC, SCR, GPF, catalytic converters
• Drying temperature: 20°C–220°C
• Main systems: Water heating, ventilation, drying, lighting, circulation pump, filter holder mechanism, water and air mixing system, liquid level sensor, PLC with touchscreen, filtration system, electrical protection.
• Cleaning fluid used: 2531
