Body dent removal mechanism GYS Airfix Draw

Body dent removal mechanism GYS Airfix Draw

GYS Airfix Draw is a very useful device for all auto body specialists who carry out dent removal work. It has a patented structural design that features a non-glued, recessed sole attachment mechanism. If needed, this seal can be replaced in a matter of moments. In addition, in the created vacuum, special cushions prevent the device from sliding, so this method of fixation provides additional strength. All these features put together make this mechanism one of the most beneficial dent removers on the market.

Innovative and patented design:

• The pull-up plate has 4 rubber pads that absorb pulling forces during ironing and stretching
• The surrounding seal is recessed without glue
• Gasket and plate pads - easily replaceable

Powerful and efficient pulling:

• A pulling force of 350 kg is ensured, over the entire height of the column of the device
• Maximum pulling height 1320 mm
• Traction winch with 6 mm diameter rope. (Ensuring safe towing up to 1000 kg)
• The height of the winch is adjustable, it can be done in seconds and requires no tools
• Built-in gear that will facilitate pulling down

Ergonomic design:

• Low weight (31 kg) and easy positioning of the device thanks to the built-in two wheels
• Not making a lot of noise, thanks to high-quality noise-absorbing materials

Usage:

• Select the correct position of the device
• Connect the compressed air hose to the unit
• Do the straightening

Technical parameters:

• Column height: 1250 mm
• Sole dimensions: 368 x 610 mm
• Weight: 68 kg
• Max Pressure: 72 > 116 psi
• Connection for compressed air: R 1/4
