Blasting booth set PS PAL3-L Sabbiatrici

Blasting booth set PS PAL3-L Sabbiatrici

Country of origin: Italy, warranty period - 24 months

Possible additional modifications and various accessories are available upon request

The PS PAL3-L vacuum-type blasting and shot peening booth is intended for professional surface treatment in various fields – industry, restoration, or technical maintenance. It allows for shot peening, decorative sandblasting, metal hardening, deburring, surface cleaning, and other processing tasks. By using different abrasives (corundum, sand, glass microspheres, synthetic or vegetable granules, metal abrasives), it is possible to work with various materials. The booth can be optionally equipped with a dust filter system, rotary table, loading cart, or abrasive regeneration cyclone. If needed, the system can be converted into a pressure-type version, increasing performance and enabling more efficient surface engraving.

Functions:

• Suitable for shot peening, sandblasting, metal hardening, cleaning, and surface preparation
• Compatible with various abrasives: corundum, sand, glass microspheres, metal or vegetable granules
• Convertible to a pressure system
• Optional accessories: dust collection filter, loading cart, rotary table, cyclone
• Suitable for working with aluminum, iron, glass, stainless steel, etc.
• Enables deep engraving or light polishing of surfaces

Technical specifications:

Internal dimensions:

• Front – 1180 mm
• Side – 800 mm
• Height – 780 mm

External dimensions:

• Front – 1220 mm
• Side – 1260 mm
• Height – 1900 mm

Booth access: side, from both left and right

• Dust extractor: 400 V, 50 Hz, 0.75 kW
• Lighting: LED 20 W

Air consumption:

• Injector ∅ 3 mm – 600 l/min
• Injector ∅ 3.5 mm – 800 l/min
• Injector ∅ 4 mm – 1200 l/min
• Operating pressure: from 1.5 to 8 bar
• Tungsten carbide nozzle: ∅ 6, 8, or 10 mm
• Weight: 180 kg

Set includes:

• Blasting booth PS PAL3-L
• Wear-resistant rubber lining
• Pressure tank (24 L)
• Dust collection filter with self-cleaning compressed air system
