Workshop jack for heavy-duty vehicles 10 tons Mammuth
Country of origin: Netherlands, warranty period - 24 months

The Mammuth 10-ton industrial workshop jack is a reliable tool designed for lifting heavy vehicles such as trucks, agricultural machinery, or commercial vehicles. Thanks to the FTL (Fast to Load) system, the jack’s platform reaches its maximum height with just three full pump strokes when unloaded, significantly increasing work efficiency. The ergonomically adjustable handle and controlled lowering speed ensure safe, precise, and comfortable use even under intensive working conditions.

Functions:
  • FTL (Fast to Load) system – maximum lifting height reached in 3 pump strokes without load
  • Controlled lowering speed – safe and smooth descent under load
  • Adjustable handle – convenient and ergonomic operation
  • 10-ton lifting capacity – ideal for lifting trucks, tractors, and other heavy-duty vehicles
Technical specifications:
  • Lifting capacity: 10000 kg
  • Minimum lifting height: 160 mm
  • Maximum lifting height: 650 mm
  • Platform diameter: ø150 mm
  • Pump rod length: 1153 mm
  • Front wheel diameter: ø141 mm
  • Rear wheel diameter: ø91 mm
  • Oil capacity: 1.050 l
  • Oil type: OKCH68
  • Handle length: 1083 mm
  • Stroke: 490 mm
Product dimensions:
  • Length: 1637 mm
  • Width: 494 mm
  • Height: 249 mm
  • Weight: 133.0 kg
Package dimensions:
  • Length: 1670 mm
  • Width: 520 mm
  • Height: 330 mm
  • Weight: 149.0 kg
