Welding wire 1.0 mm 15 kg

Welding Wire 1.0 mm 15 kg

Country of origin: China, warranty period – 24 months

This 1.0 mm copper-coated welding wire, weighing 15 kg, is designed for high-quality gas welding on carbon steel, as well as unalloyed or low-alloy steel. Due to its excellent mechanical properties, high corrosion resistance, and stable arc behavior, the wire is widely used in the automotive, shipbuilding, and railway industries, as well as in construction and the manufacturing of tanks and boilers. It is suitable for welding in all positions.

Features:

• Excellent ignition properties and high arc stability at elevated currents
• Good resistance to corrosion
• Suitable for all welding positions
• Designed for use with CO₂ or Argon/CO₂ gas mixtures
• Ideal for metal structures and various industrial applications

Technical Specifications:

• Diameter: 1.0 mm
• Weight: 15 kg

Classification:

• AWS 5.18: ER 70S-6
• EN ISO 14341-A: G46 4 M21 3Si1 / G 42 3 C1 3Si1
• DIN 8559: SG2
• Polarity: DC+

Chemical Composition:

• C: 0.087%
• Mn: 1.66%
• Si: 0.92%
• S: 0.015%
• P: 0.017%
• Cu: 0.30%
• Cr: 0.077%
• Ni: 0.16%
• Mo: 0.11%
• V: 0.002%
• Al: 0.008%

Mechanical Properties:

• Yield Strength (Re): 469 MPa
• Tensile Strength (Rm): 582 MPa
• Elongation (A5d): 26%
• Impact Strength at -30°C (KV): 81 J

Recommended Settings:

• Wire: Ø 0.8 mm (recommended)
• Material thickness: < 5 mm
• Voltage: 16–28 V
• Current: 60–200 A

Shielding Gas Types (per EN ISO 14175):

• 100% CO₂ (C1)
• Argon with 8–20% CO₂ (M21)
