Welding equipment for TIG and MMA welding GYS PROTIG 160 DC LIFT

Welding Equipment for TIG and MMA Welding GYS PROTIG 160 DC LIFT

Country of origin: France, warranty period - 24 months

PROTIG 160 DC LIFT is an ultra-compact welding machine designed for professional work using TIG DC and MMA welding methods. It ensures high-quality weld seams on mild and stainless steel, while its intuitive interface allows for easy adjustment of welding parameters. The Lift ignition function helps prevent electrical interference in sensitive environments.

Features:

• TIG DC – High-quality welding for ferrous and stainless metals.
• Lift ignition – Safer ignition without contact with the electric arc, ideal for sensitive environments.
• Pulsed welding – Adjustable manually or automatically for optimal heat input control.
• Automatic torch detection – Compatible with one or two-button torches.
• MMA Welding – Welding current from 20 to 160 A, suitable for basic, rutile, stainless steel, and cast iron electrodes (up to Ø 4 mm).
• Integrated auxiliary functions:
• Anti-stick – Prevents electrode sticking.
• Hot Start – Facilitates arc ignition with adjustable intensity.
• Arc Force – Stabilizes the arc in complex welding situations.
• Protection systems:
• Optimized cooling system with thermal protection.
• Resistance to overvoltage up to 400 V.
• Compatibility with power generators.
• Compact and lightweight – Weighs only 5.1 kg, making it easy to transport.

Technical Specifications:

• Voltage: 230 V ~ 50/60 Hz
• Welding current (TIG mode): 20–160 A
• Welding current (MMA mode): 20–160 A
• Duty cycle (TIG, 60% at 40°C): 95 A
• Duty cycle (MMA, 60% at 40°C): 80 A
• Open circuit voltage: 72 V
• Protection class: IP 21
• Dimensions: 28 × 13 × 25 cm
• Weight: 5.1 kg
• Generator power requirement: 6 kW / 7.5 kVA
