Vertical truck tire mounting machine BD-990

Vertical truck tire mounting machine BD-990
Vertical truck tire mounting machine BD-990
Pre-order
3,950.00€
Ex Tax: 3,264.46€
Prices include VAT
Want to buy or learn more?

Fill out the inquiry form

Vertical Truck Tire Mounting Machine BD-990

Country of origin: China, warranty period – 24 months

The BD-990 is a specialized vertical truck tire mounting machine designed for efficient and safe operation with the rims and tires of trucks, buses, and other heavy-duty vehicles. Thanks to its vertical mounting mechanism, this machine helps save workspace, while its hydraulic system ensures precise and accurate operation. Reliable hydraulic components and a robust construction guarantee durability and convenient use, even under heavy workloads.

Features:

  • Dual-direction tire mounting head – allows for more flexible and user-friendly tire mounting.
  • Special rim clamps – securely fix aluminum rims without causing damage or leaving marks.
  • Adjustable tire bead pressing roller – can be adapted to the rim position and size even during operation.
  • Hydraulic motor drive with a high-capacity reservoir – ensures greater work efficiency.
  • Foot pedal control – enables rotation of the rim with the tire clockwise or counterclockwise.
  • Control column with control levers – equipped with an emergency stop button for enhanced safety.
  • Enclosed drive mechanism – protects against dust penetration and extends equipment lifespan.

Technical Specifications:

  • Clamping rim diameter: 14" – 26"
  • Maximum wheel diameter: 1400 mm
  • Maximum wheel width: 780 mm
  • Maximum wheel weight: 500 kg
  • Hydraulic operating pressure: 130 bar
  • Bead breaking force: 2700 kg
  • Motor power: 3 kW
  • Power supply: 400 V / 50 Hz / 3-phase
