Universal semi-trailer diagnostic equipment Jaltest PC Link

Universal Semi-Trailer Diagnostics – Jaltest PC Link

Warranty period – 24 months

Why Choose Jaltest PC Link?

• One device for everything
• A single tool serves multiple types of vehicles—no need for separate diagnostic systems.
• Fast adaptation to different connectors
• A universal diagnostic cable with a set of special adapters allows quick connection to various vehicle types.
• Automatic multiplexer
• Automatically adapts to the OBD structure—no manual switching required.
• A future-proof solution
• Supports a wide range of protocols, including the latest Euro standards and various CAN versions.
• Built for harsh conditions
• Durable shock-resistant housing ensures reliable operation in demanding environments.
• Software and support included
• Choose from different software packages for trucks, buses, and vans. Additional cable kits are available for extended compatibility.

Features:

• Electronic Control Unit (ECU) diagnostics via OBD interface or specific adapter
• Ability to connect to any diagnostic port using a universal diagnostic cable with special adapters
• Integrated automatic multiplexer – automatic switching of K and L, CAN, SAE lines to any OBD terminal
• Supported diagnostic protocols: ISO 9141-2, K/L lines; ISO 14230 (KWP2000), K/L lines; SAE-J1850 VPW and PWM; ISO 11519-2; SAE J1708; ISO 15765-4 (OBD); CAN ISO 11898; CAN (High Speed, Medium Speed, Low Speed, single-wire CAN support); SCI Haldex; RP 1210; SAE J2534 (PASS-THRU)

Technical Specifications:

• Connects to a desktop or laptop PC via Bluetooth or USB cable
• Bluetooth range: 20–50 m
• Minimum PC requirements: DVD drive, Windows XP, 7, 8, 10 64-bit OS, 2 GB RAM, 10 GB free hard disk space, USB port
• Powered via OBD connector or 12/24 V DC power supply
• Power consumption: 7W
• Shock-resistant housing
• Weight: 1.2 kg
• Dimensions: 183 x 131 x 56 mm
• Operating temperature: 0°C to +45°C
• Multilingual menu
• Certifications: CE, FCC, RoHS

Standard Kit Includes:

• JALTEST PC LINK interface
• OBD cable JDC213M3
• USB cable JDC107.4
• Carrying case 29380
• Universal diagnostic cable with a set of special adapters JTP96
• Power cables for battery and vehicle power outlet

Additional Configurations:

• Cable kit for truck and bus diagnostics (8 pcs.) (Volvo, Mercedes-Benz, Scania, Renault, Iveco > 1998, MAN – TGA, TGL, TGM, DAF, MAN F2000)
• Thermo King diagnostic cable COJALI JDC113A
• JalTest Soft + INFO Online software for truck, trailer, bus, and van diagnostics
• JalTest Soft + INFO Online 12-month update subscription
• Diagnostic software packages for trucks and tractors
• Diagnostic software package for buses
• Diagnostic software package for vans and light commercial vehicles

Who Is This Device For?

• Jaltest PC Link is ideal for workshops, independent truck, bus, and machinery technicians, transport companies, and maintenance professionals working with mixed-brand vehicle fleets. It’s the right choice for those seeking versatility, reliability, and efficiency in daily diagnostics.

Work smarter – choose Jaltest!

• Invest in a universal diagnostic system that adapts to your needs. Contact us for a consultation or request a free trial – see for yourself what Jaltest PC Link can do for your workshop!
