Universal light commercial vehicle diagnostic tool Jaltest PC Link

Universal Light Commercial Vehicle Diagnostic Tool – Jaltest PC Link

Warranty period – 24 months

Why Choose Jaltest PC Link?

• Tailored for the LCV Segment
• Optimized for the diagnostics of light commercial vehicles (vans, pickups, etc.) – highly compatible with the most recognized manufacturers.
• Practical Diagnostics Without Limits
• Connect to any interface using a universal cable and adapter set.
• Clear and Convenient Operation
• The intuitive software enables quick system analysis, parameter monitoring, and fault identification.
• Flexible Usage
• Diagnostics can be performed via USB or Bluetooth – ideal for mobile service setups.
• Expandable Functionality
• Optional cable kits and software packages allow expansion into other vehicle groups.

Functions:

• ECU (Electronic Control Unit) diagnostics via OBD interface or specific adapter
• Ability to connect to any diagnostic port using a universal diagnostic cable with special adapters
• Integrated automatic multiplexer – automatic switching of K and L, CAN, and SAE lines to any OBD terminal
• Supported diagnostic protocols: ISO 9141-2, K/L lines; ISO 14230 (KWP2000), K/L lines; SAE-J1850 VPW and PWM; ISO 11519-2; SAE J1708; ISO 15765-4 (OBD); CAN ISO 11898; CAN (High, Medium, Low Speed, single-wire CAN); SCI Haldex; RP 1210; SAE J2534 (PASS-THRU)

Technical Specifications:

• Connects to a desktop or laptop PC via Bluetooth or USB cable
• Bluetooth range: 20–50 m
• Minimum PC requirements: DVD drive, Windows XP, 7, 8, 10 (64-bit), 2 GB RAM, 10 GB free HDD space, USB port
• Powered via OBD connector or 12/24 V DC power supply
• Shock-resistant housing
• Weight: 1.2 kg
• Dimensions: 183 x 131 x 56 mm
• Operating temperature: 0°C to +45°C
• Multilingual menu
• Certifications: CE, FCC, RoHS

Standard Kit Includes:

• Jaltest Modular Light Commercial Vehicle software
• Jaltest Modular Light Commercial Vehicle license

Optional Add-ons:

• Truck and bus diagnostic cable kit (8 pcs): Volvo; Mercedes-Benz; Scania; Renault; Iveco > 1998; MAN (TGA, TGL, TGM); DAF; MAN F2000
• Thermo King diagnostic cable COJALI JDC113A
• JalTest Soft + INFO Online software for diagnostics of trucks, trailers, buses, and vans
• JalTest Soft + INFO Online 12-month update subscription
• Software package for truck and tractor diagnostics
• Software package for bus diagnostics

Who Is This Device For?

• Jaltest PC Link is the ideal solution for auto repair shops, independent light commercial vehicle technicians, and maintenance professionals who need precise, mobile, and fast diagnostics for vans, pickups, and other commercial vehicles.

Trust begins with a reliable tool!

• Contact us for a live demonstration or try Jaltest PC Link in real-life conditions – and see for yourself why it's the most trusted choice for your workshop!
