Unimetal RHO-6 brake test bench for cars up to 3.5 tons
Installation is available upon request!
The price includes the brake testing stand and the control unit!
Additionally, it is necessary to purchase a computer set or other accessories such as a concrete mounting frame, wireless control panel, and others!
- SKU: BD04030
10,999.00 €
Send Message
Description
Brake Testing Stand up to 3.5t UNIMETAL RHO-6
Country of origin: Poland, warranty period – 24 months
The Unimetal RHO-6 is a modern roller brake testing stand designed for checking the brake systems of passenger cars, light commercial vehicles, motorcycles, trailers, and 4x4 drive vehicles. The unit can operate as a standalone testing station or be integrated into the comprehensive UNILINE QUANTUM 2000 testing line. It features a microprocessor-based control system and uses UNILINE QUANTUM software, which allows for accurate, user-friendly testing and result analysis. The robust construction ensures long-term durability, and the stand is suitable for low-clearance vehicles. It supports multilingual operation and can be installed in both pit and non-pit configurations.
Features:
- Suitable for passenger cars, motorcycles, light commercial vehicles, trailers, and 4x4 vehicles
- Can operate independently or as part of a full testing line
- Available in pit and non-pit versions
- Corrosion-resistant finish – galvanized, primed, and powder-coated
- Supplied with a mounting frame
- Suitable for low-clearance vehicles
- 4x4 testing functionality available upon request
- UNILINE QUANTUM software with advanced analysis capabilities
Technical Specifications:
- Maximum axle load: 2 tons
- Brake force measurement range: 0–6 kN
- Track width: 900–2140 mm
- Supported wheel diameters: 10–28 inches
- Motor power: 2 x 4 kW
- Electromagnetic brake with automatic motors
- Coefficient of friction (dry/wet tires): 0.9 / 0.7
- Test speed: 5 km/h
- Power supply: 400 V / three-phase
Standard Equipment:
- Control unit (without computer)
- Wireless remote control
- Mounting frame for concrete installation
Optional Equipment (upon request):
- Mounting frame for in-ground installation
- Automatic 4x4 transmission detection and 4WD testing functionality
- Roller covers for motorcycle testing
- Weighing system for RHO stand
- Electromagnetic brake (for RHO model)
- Plates between rollers for in-ground RHO stands
- Roller covers for RHO stands
- Hydraulic axle load simulator (for in-ground versions only)
- Wireless pressure gauge
- Brake pedal pressure sensor (0–1000 N)
- Parking brake pressure sensor
- Pneumatic wheel clamps
