Tyre changer and wheel balancer set BD70427 + BD70419 Hofmann

Wheel Balancer geodyna® 7340L + Tyre Changer monty® 3300-24 smartSpeed™ EM

Country of origin: Italy, warranty period – 24 months

This is a high-quality "Hofmann" wheel service equipment set designed for professional use in automotive workshops. The set includes the geodyna® 7340L automatic wheel balancer and the monty® 3300-24 smartSpeed™ EM tyre changer, both ensuring fast, accurate, and safe operation with passenger vehicle wheels. This set is an ideal solution for workshops looking to optimize workflow and improve service quality.

Wheel Balancer geodyna® 7340L

Features:

• Touchscreen display with user-friendly interface – for easy and fast operation.
• Dual-user configuration – allows two operators to work simultaneously.
• smartSonar™ – automatic wheel width detection using ultrasonic sensors.
• easyWeight™ – laser technology for precise placement of wheel weights.
• easyALU™ – quick selection of aluminum wheel balancing mode.
• Mechanical clamping system
• Ergonomic design – built-in weight tray simplifies the work process.

Technical specifications:

• Dimensions: (180 x 152 x 135 cm)
• Manual rim diameter range: 8” - 32” (20 - 81.2 cm)
• Manual rim width range: 1” - 20” (2.5 - 50.8 cm)
• Maximum rim width: 20" (51 cm)
• Maximum wheel diameter: 42” (107 cm)
• Maximum wheel weight: 70 kg
• Net weight: 115 kg
• Power supply: 115V 1Ph 60Hz
• Semi-automatic rim diameter range: 8” - 25” (20 - 63.5 cm)
• Semi-automatic rim width range: 3” - 15” (7.6 - 38 cm)

EASYWEIGHT™

• This precise weight positioning system eliminates guesswork and streamlines the balancing process. It uses a laser to indicate the exact spot for applying weights, ensuring flawless balance and highly accurate results.

EZ-COLLETS MOBILE APP

• The EZ-Collets mobile app is a useful tool that helps technicians find the correct clamping handle, flange, or quick-release hub based on the job’s specific requirements. By selecting the vehicle being serviced, users can compare and assess different tool options using the app.

INTEGRATED TOUCH DISPLAY

• This system features a raised monitor and an integrated touch control panel, providing convenient operation, optimized workflow, and a simplified balancing process.

Mechanical Clamping System

QUICKBAL™

• Designed for optimal workflow, this feature smartly adjusts the number of rotations based on each wheel's specifications. Operating at maximum speed, it reduces the balancing cycle time, delivering fast and efficient results.

REPORT GENERATION

• Easily generate reports over a local network (additional hardware required) or save them as PDF files on a USB drive. This makes it convenient to share detailed data with customers for documentation or reference purposes.

SEMI-AUTOMATIC DATA INPUT

• The device features a convenient measuring arm that simplifies data entry using the easyALU™ assisted rim measurement technology. The technician only needs to touch the rim with the arm, and the system automatically inputs the rim dimensions and selects the appropriate balancing mode.

SMARTSONAR™

• This intelligent system uses sonar sensors to automatically detect rim width, eliminating the need for manual input and reducing the likelihood of errors. By optimizing the process, it increases work efficiency and accuracy.

SPLIT WEIGHT MODE (HIDDEN WEIGHT BEHIND SPOKES)

• This function ensures precise balancing and allows wheel weights to be hidden behind spokes, maintaining the aesthetic appearance and visual appeal of the wheels.

Tyre Changer monty® 3300-24 smartSpeed™ EM

Features:

• Vertical arm design – allows easy tyre loading and operator comfort.
• smartSpeed™ – automatic adjustment of wheel rotation speed.
• easymont® pro – facilitates the mounting of stiff tyres.
• Floor-mounted side bead breaker – efficient bead separation.
• Self-centering clamps with 3-step manual adjustment – for secure rim holding.
• Nylon rim protector – prevents scratches and damage.
• Tool tray with pressure gauge and shelves – for organized workflow.

Technical specifications:

• Maximum tyre width: 13" | 33 cm
• Maximum wheel diameter: 39" | 100 cm
• Power supply: 230V 1ph 50-60Hz 16A
• Dimensions: 162 x 169 x 126 cm
• Maximum rim diameter: 24" | 61 cm
• Maximum rim width: 12" | 31 cm
• Required air pressure: 116-174 PSI | 8-12 bar

Adjustable Clamping Jaws

• To protect the rim, these nylon-coated jaws are self-centering and grip the wheel securely, ensuring greater stability and safety.

Tyre Bead Breaker (Foot Pedal Control)

• The floor-mounted bead breaker with a convenient pedal allows quick and easy removal of various tyre types. This is the fastest solution for efficiently removing different tyres.

Pneumatic Tyre Mounting Assist System

• Consisting of an upper roller, pressure pad, and lifting disc, this comprehensive pneumatic assist system simplifies the mounting and removal of low-profile and high-performance tyres, allowing a single technician to handle them with ease.

smartSpeed™ Technology

• This revolutionary patented technology optimizes the torque applied to the wheel and automatically determines the maximum rim rotation speed, ensuring smooth and safe operation.

Tilt-Back Arm

• With a pneumatic design, this feature maximizes workspace efficiency by making it easier to position the tyre on the tabletop.

Tool Tray with Integrated Air Pressure Gauge

• Safely stores tools and features four convenient shelves for organizing valves, accessories, and tools.
