Two-post lift ATH-Comfort 2.40 (Germany)
Two-post lift ATH-Comfort 2.40 (Germany)
-4 %

Two-post lift ATH-Comfort 2.40 (Germany)

  • SKU: BD11840
4,174.50 €

4,356.00 €
Prices shown include tax

Send Message

Description

Two-post lift ATH-Comfort 2.40 (Germany)
Country of origin: ATH-Heinl (Germany); Warranty 36 months
Description:
  • High quality and robust electro-hydraulic 2-column lift
  • Quick lifting and lowering with powerful hydraulic unit and lowering speed control valve
  • Multifunctional operating range with telescopic lifting paws, optionally asymmetrical (short - long) or symmetrical (long - long) version
  • Electromagnetic safety interlock system
  • Automatic electromagnetic locking system
  • Very low access above the plate (height: 20 mm) for comfortable workshop work and protection of hydraulic hoses and timing ropes
Specification:
  • Supply voltage: 3/400 V / 50 Hz
  • Lifting capacity: 4000 kg
  • Durability of concrete: C20 / 25
  • Passage width: 2500 mm
  • Base depth without floor covering: 200 mm
  • Overall width: 3542 mm
  • Lifting / lowering time: approx. 30s
  • Max. lifting height: 2000 mm
  • Engine power: 3 kW
