Two-column cargo lift Zafer 1000 kg

Two-column cargo lift Zafer 1000 kg

Two-column cargo electrohydraulic lift - widely used in warehouses and factories and outdoors, when you want to lift goods or pallets between different floors. These are also called wall-mounted cargo lifts. They provide an opportunity to quickly, efficiently, conveniently and safely lift your cargo to any floor comfortably, as there are control panels on different floors, which will give you mobility.

All cargo lifts can be manufactured according to special orders, according to technical needs. So you can choose according to the parameters that are convenient for you or according to what solution would be the most comfortable in the existing premises. All the parts made for the structure are of the highest quality, and the lift itself has CE and ISO certificates.

Technical parameters:

• Supply voltage: 400 V / 50 Hz / 3 fz
• Coating: powder paint
• Height of protective wall: 700 mm
• Platform dimensions: according to individual needs
• Load capacity: up to 1000 kg

Standard equipment:

• Control panels at all stops
• 700 mm high wall at the edges of the platform
• Hydraulic control station that can be built separately from the lift
• A lifting mechanism that is made according to individual needs
• Electric motor

Additional components available:

• Segmental, steel fence around the lift, cage
• Lift shutters
• Opening doors
• Mechanical gates
• Electromagnetic gate
• Mechanical or electromagnetic security locks
