Description
Truck Wheel Washing Equipment WULKAN 500HP
Country of origin: Poland, warranty period - 24 months
WULKAN 500HP is a fully automatic wheel washing system designed for all types of truck wheels with a width of up to 490 mm and a diameter of up to 1200 mm. The device utilizes an efficient washing method that combines water, Wulkan MIX granule technology, and Wulkan Turbo washing concentrate. The closed water system ensures economical and environmentally friendly operation. The unit is equipped with a water heating system, pneumatic wheel mounting and dismounting systems, and an additional pneumatic wheel push-out function from the washing chamber, ensuring maximum user convenience.
Features:
- Fully automatic washing process
- Water heating system
- Pneumatic wheel mounting/dismounting system
- Pneumatic wheel push-out system
- Uses a natural self-cleaning technology
- Double sound insulation (rubber lining, foam)
- Anti-vibration rubber feet for stability
- Sedimentation tank separated from the washing chamber
- Convenient control computer with a display
- Software available in six languages
- Drain hose valve for easy water removal
- Easy to install and operate
- Energy-efficient operation
Heating System:
- Heater power: 4 kW
- Water heating time up to 50°C: 120 - 180 min
- Overheating protection
Standard Equipment:
- Wulkan MIX granules – 50 kg
- Granule basket
- Wulkan Turbo washing concentrate – 50 L
- Rubber anti-slip mat
Technical Specifications:
- Wheel diameter range: 740 - 1200 mm
- Wheel width range: 240 - 490 mm
- Maximum wheel weight: 150 kg
- Washing time (adjustable, 3 programs): 60, 120, 240 sec
- Drying time (adjustable, 1 program): 30 sec
- Water heating time up to 50ºC: 120 - 180 min
- Heater power: 4 kW
- Pump drive power: 5.5 kW, 3-phase, 400 V, 50 Hz, 2900 rpm
- Pump capacity: 600 LPM
- Drive wheels: 3-phase, 400 V, 50 Hz, 0.37 kW, 930 rpm
- Total motor and drive power: 7 kW
- Water pressure: 4 bar
- Water capacity: 500 L
- Wulkan MIX granules quantity: 40 kg
- Wulkan TURBO washing concentrate quantity: 5 L
- Compressed air operating pressure: 8 - 12 bar
- Acoustic power level: 89.9 dB
- Dimensions (width x depth x height): 1360 x 1629 x 2160 mm
- Weight: 680 kg
- Available colors: red, blue
Dimensions:
.png)
.png)
