Tire pressure monitoring system (TPMS) diagnostic equipment, LAUNCH CRT 511S V2

Tire Pressure Sensor (TPMS) Diagnostic Tool LAUNCH CRT 511S V2

Functions:

• Activation, programming, reprogramming, and diagnostics of TPMS sensors
• Intelligent tire pressure configuration
• TPMS report generation (can be sent to customers or colleagues)
• Workshop data can be included in the report

OBD II Functions:

• Quick DTC (Diagnostic Trouble Code) reading
• Fault cause identification
• MIL (Malfunction Indicator Lamp) analysis
• Monitor readiness check before emissions testing
• Diagnostics and services related to emissions

Data Management:

• Access to DTC code library
• DLC codes and online lookup
• Screenshot capture
• Feedback submission, FAQs, and product manual

12 Service Functions:

• DPF regeneration
• Immobilizer function (key registration)
• Injector coding
• Seat calibration
• Sunroof reset
• Window calibration
• Oil maintenance reset
• Brake system reset
• Battery matching
• Steering angle sensor reset
• Electronic throttle relearning
• ABS air bleeding

Technical Specifications:

• Display: 5-inch, 720 × 1280 dpi
• Memory: 2 GB RAM + 32 GB ROM
• Battery: 6000 mAh
• OBD II Input Voltage: 9 ~ 18 V
• Operating Temperature: 0°C ~ 50°C
• Dimensions: 159 × 88 × 37 mm
